Name: Суич Ubiquiti Pro XG 10 PoE (USW-PRO-XG-10-POE), 10 000 Mbps, 12 порта, 10x 10/100/1000/2500/10000Mbps RJ45 PoE+++, 2x SFP+
Brand: Ubiquiti
SKU: NTLHUBIQUITIUSWPROXG10POE
Availability: OutOfStock

Описание Характеристики Ревюта / Въпроси

Ubiquiti Pro XG 10 PoE

Category	Specification
Dimensions	442.4 x 285 x 44 mm (17.4 x 11.2 x 1.7")
Form Factor	Rack mount (1U)
Weight	Without mounting brackets: 4.6 kg (10.14 lb) With mounting brackets: 4.7 kg (10.36 lb)
Enclosure Material	SGCC steel
Mount Material	SGCC steel
Supported Rack Depth	400–1200 mm (15.7–47.2")
Display	1.3" touchscreen LCM
Port Layout	10× 10 GbE RJ45 (All PoE+++) 2× 10G SFP+ (10G/1G)
PoE Ports	10 (All PoE+++)
Max. PoE Wattage per Port	PoE: 15.4W PoE+: 30W PoE++: 60W PoE+++: 90W
Total PoE Availability	400W
Max. Power Consumption	65W (Excluding PoE output) 520W (Including PoE output)
Power Supply	AC/DC, internal, 550W
Power Method	(1) Universal input, 100–240V AC, 50/60 Hz (1) USP RPS DC input
Power Input Method	AC input
Supported Voltage Range	100–240V AC
Redundancy	DC Power Backup (USP RPS)
Layer 3	✓
Switching Capacity	240 Gbps
Total Non-Blocking Throughput	120 Gbps
Forwarding Rate	179 Mpps
Supported VLANs	1,000
MAC Address Table Size	32,000
L3 Table Size	ARP Entries: 12,000 IPv4 Routes: 12,000
Packet Buffer Size	2 MB
Access Lists	IPv4: 128 MAC: 128
Networking Features	DHCP Server (Local Networks): ✓ DHCP Relay: ✓ Inter-VLAN Routing: ✓ Static Routing: ✓
Advanced Networking	LACP Port Aggregation: ✓ STP & RSTP: ✓ QoS (DSCP): ✓ Pro AV Profiles: ✓
Multicast Management	IGMP Snooping: ✓ Advanced IGMP (Querier, Fast Leave, Router Port): ✓
Security Features	802.1X Control: ✓ MAC-Based ACLs & Isolation: ✓ DHCP Snooping & Guarding: ✓ IP-Based ACLs & Isolation: ✓
Traffic Control	Egress Rate Limit: ✓ Flow Control: ✓ Storm Control: ✓ Multicast & Broadcast Rate Limiting: ✓
Additional Features	MAC Address Blocking: ✓ MAC-Based Port Restriction: ✓ Port Isolation: ✓ Port Mirroring: ✓ Jumbo Frames: ✓
Voice & LLDP	Voice VLAN: ✓ LLDP-MED: ✓
Loop & Fail Protection	Loop Protection: ✓
Etherlighting™	Ethernet: ✓ SFP+: ✓
LEDs	RPS: ✓ System: ✓
Environmental Protection	ESD/EMP Protection: Air ±30kV, Contact ±30kV
Ambient Operating Temperature	-5 to 40° C (23 to 104° F)
Ambient Operating Humidity	10 to 90% noncondensing
Compliance & Certifications	NDAA Compliant: ✓ Certifications: CE, FCC, IC
Software Compatibility	UniFi Network Version 9.1.120 and later
