CCR1016-12S-1S+
CCR1016 is an industrial grade router with a cutting edge 16 core Tilera CPU. If you need many millions of packets per second - Cloud Core Router is your best choice.
This model has twelve SFP ports and one SFP+ port for 10G connectivity. It is available in a 1U rackmount case and also has a serial console port, a touchscreen LCD and a USB port.
The CCR1016-12S-1S+ comes with redundant power supplies and one RJ45 SFP 10/100/1000M copper module.
SFP+ cage supports regular SFP (1.25G) modules as well.
SFP DDMI Yes
CPU nominal frequency 1.2 GHz
CPU core count 16
Size of RAM 2 GB
Architecture TILE
10/100 Ethernet ports None
10/100/1000 Ethernet ports None
MiniPCI slots 0
MiniPCI-e slots 0
Wireless chip model None
Number of USB ports 1
Power Jack 2
802.3af support No
Supported input voltage 24 V - 24 V
PoE in No
PoE out No
Voltage Monitor Yes
CPU temperature monitor Yes
PCB temperature monitor No
Operating System RouterOS v6
Operating temperature range Max ambient temperature 50° @ 1.2GHz; 70° @ 1GHz CPU core frequency
License level 6
Current Monitor Yes
CPU TLR4-01680CG-12CE-A3a
Max Power consumption 44 W
SFP ports 12
SFP+ ports 1
USB slot type microUSB type AB
Serial port RS232
Included parts:
IEC cord
Rack ears
RJ45 SFP coper module
