Суич Ubiquiti USW-24-POE Gen2, 24x 10/100/1000 RJ45, 2x SFP

USW-24-POE GEN2



Dimensions
424.4 x 200 x 43.7 mm

Weight
With Rackmount Brackets 3.00 kg (6.61 lb)

Interfaces
(24) 10/100/1000 RJ45 Ports
(2) 1G SFP Ethernet Ports

Ethernet In-Band
Power Method 100-240VAC/50-60 Hz, Universal Input
Power Supply AC/DC, Internal, 120W
Supported Voltage Range 100 to 240VAC
Max. Power Consumption (Excluding PoE Output) 25W


ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC


POE
PoE Interfaces Ports 1-16 POE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-)
Max. PoE Wattage per Port by PSE
802.3at
32W
Voltage Range 802.3af Mode 44-57V
Voltage Range 802.3at Mode 50-57V
