Name: Суич Cudy GS1020PS2, 52000 Mbps, 18 порта, 16x 10/100/1000 Mbps RJ-45, 2x SFP 100/100/1000 Mbps
Brand: Cudy
SKU: NTLHCUDYGS1020PS2
Price: 170.90 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси

Cudy GS1020PS2

Specifications

Connector Type	1610/100/1000M PoE Ports + 2Gigabit SFP Uplink Ports
Network Media (Cable)	IEEE802.3 IEEE802.3u IEEE802.3x IEEE802.3ab IEEE802.3z
PoE Parameters	PoE Standard: IEEE802.3af /IEEE802.3at
	Max each port: 15.4W ( IEEE 802.3af ) Max each port：30W ( IEEE 802.3at )
	PoE compatibility: IEEE 802.3af/at adaptive
	PoE port output: DC48-55V
	Power Pin : Power over spare pairs 1/2(+) , 3/6 (-)
Network Media	10BASE-T: Cat 5E UTP(≤250 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter) 1000BASE-TX: Cat5 or more UTP (≤100 meter)
Optical	MultiMode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km
Performance Specification	Bandwidth: 52Gbps
	MAC: 8K
	Packet Buffer Memory: 4M
	Packet Forwarding Rate: 38.7Mpps
Power Supply	Power input: AC100-240V 50/60Hz, Power Budget: 200W
LED Indicator	PWR	Power supply indicator (Red)	Lighting：Powered Un-Light：No Power
	1-26	RJ-45 LINK indicator (Green)	Lighting：1000M Connect Un-Light：100M or Disconnect
	1-26	RJ-45 ACT indicator (Green)	Lighting：Connecting Flashing：Data Transmit Un-Light：Disconnect
Working Environment	Operating Temperature: -20℃ ~ 50℃; Storage Temperature: -40℃ ~ 80℃; Operating Humidity: Max 90%, non-condensing Storage Humidity: Max 95%, non-condensing Working Height: Max to 10,000 feet (3,000 meters) Storage Height: Max to 10,000 feet (3,000 meters)
