Cudy GS1020PS2
High Quality TPS PoE chipset inside
High Quality TPS PoE chipset inside ensure High performance and stable operation of the product. | .png) |
Auto-sensing technology The port power prioritization technology ensures the continuous power supply of the key nodes. | .png) |
Lightning protection
Electrostatic standard: contact 6KV, air 8KV MTBF > 50000 hour | .png) |
Specifications
| Connector Type | 16*10/100/1000M PoE Ports + 2*Gigabit SFP Uplink Ports | ||
| Network Media (Cable) | IEEE802.3 IEEE802.3u IEEE802.3x IEEE802.3ab IEEE802.3z | ||
| PoE Parameters | PoE Standard: IEEE802.3af /IEEE802.3at | ||
Max each port: 15.4W ( IEEE 802.3af ) Max each port：30W ( IEEE 802.3at ) | |||
| PoE compatibility: IEEE 802.3af/at adaptive | |||
| PoE port output: DC48-55V | |||
| Power Pin : Power over spare pairs 1/2(+) , 3/6 (-) | |||
| Network Media | 10BASE-T: Cat 5E UTP(≤250 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter) 1000BASE-TX: Cat5 or more UTP (≤100 meter) | ||
| Optical | MultiMode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km | ||
| Performance Specification | Bandwidth: 52Gbps | ||
| MAC: 8K | |||
| Packet Buffer Memory: 4M | |||
| Packet Forwarding Rate: 38.7Mpps | |||
| Power Supply | Power input: AC100-240V 50/60Hz, Power Budget: 200W | ||
| LED Indicator | PWR | Power supply indicator (Red) | Lighting：Powered Un-Light：No Power |
| 1-26 | RJ-45 LINK indicator (Green) | Lighting：1000M Connect Un-Light：100M or Disconnect | |
| 1-26 | RJ-45 ACT indicator (Green) | Lighting：Connecting Flashing：Data Transmit Un-Light：Disconnect | |
| Working Environment | Operating Temperature: -20℃ ~ 50℃; Storage Temperature: -40℃ ~ 80℃; Operating Humidity: Max 90%, non-condensing Storage Humidity: Max 95%, non-condensing Working Height: Max to 10,000 feet (3,000 meters) Storage Height: Max to 10,000 feet (3,000 meters) | ||
Виж още Суич Cudy
Виж всички продукти Суич в категорията
| Брой портове: | 18 |
|---|---|
| Максимална скорост: | 1 Gbit/s |
| Стандарт: | 802.3ab |
| Управляем: | Не е указано |
