★ 100% Fully Modular With All Ultra Flexible Ribbon Cables For Easy Cable Management.
★ 80 PLUS® Gold Certified,87% 90% 87% Efficiency At 20% 50% 100% Rated Load.
★ 100% Japanese 105°C Capacitors (Main Board & Modular Backpanel)
★ Full Range Auto Voltage Detection Design 100V~240V (Active PFC)
★ Comply With ATX 12V v3.0, EPS 12V v2.92 Specification.
★ Comply With Energy Star Standard & EuP (Energy Using Products) Regulation
★ Over Voltage Protection / Over Current Protection / Over Power Protection / Short Circuit Protection / Under Voltage Protection / Over Temperature Protection / No Load Operation / Surge & Inrush Protection
★ Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards (Haswell ready)
★ Support NVIDIA® SLI™ & ATI CrossFireX™ High Performance Graphic Card
★ More than 2,000 times On/Off test
★ Lead-free Green Materials with RoHS / WEEE Compliance
★ Perfect For Professional & High Performance Gaming System
★ PCI-E (6+2) Pin Connector For High-End Graphic Card Requirement.
★ Complete Japanese Capacitors.
Specifications
Transform Efficiency | 20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency |
Cybernetics Certified | Efficiency: Platinum / Efficiency 230V: Platinum |
Intel Power Design Guide | EPS Ver. 2.92 & ATX 3.0 |
AC Input | Frequency | 100V-240V | 60 / 50Hz , Full Range APFC |
Fan Size | 14cm FDB FAN |
Dimension | 150mm(L) x 150mm(W) x 86mm(H) |
Protection | OVP / OCP / OPP / SCP / UVP / OTP / NLO / SIP |
Safety Certificates | cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC |
Temperature | Passed 50℃ Hot Testing |
Cable Wires | |
20+4 Pin | One Cable (600mm) |
8(4+4) Pin CPU | Two Cables (700mm) |
PCI 6+2 Pin | Three Cables (700mm) |
4 SATA | Three Cables (550+130+130+130mm) |
4 Molex | One Cable (550+150+150+150mm) |
PCIe 16 Pin | One Cable (700mm) |
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Захранвания Настолни компютри Super Flower
Виж всички Захранвания Настолни компютри в категорията
| Изходна мощност: | 850 W |
|---|---|
| Модулен блок: | Да |
| Форм фактор: | ATX |
