Захранване Fractal Design Ion Gold, 650W, Active PFC, 80 Plus Gold, 140mm вентилатор

Fractal Design Ion Gold 650W



80PLUS® certification
Gold

Modular cables
Fully modular

Fan type
140 mm LLS bearing Fractal Design Dynamic series fan

Maximum operating temperature (full load)
40°C, 50°C at 80% load

Semi-passive operation
No

Capacitors
Primary side: Japanese 105° main bulk capacitor(s), Secondary side: Taiwanese 105°C electrolytic & solid-state capacitors

Life expectancy
100,000 hours

PSU specification compliance
ATX12V 2.52; EPS12V 2.92

PSU color
Black

Cable type
Modular 24-pin cable: Black wires in braided sleeve, Other modular cables: Flat black wires

Input voltage
100-240V AC

Input frequency
50-60 Hz
Input current
10A/5A

Protection features
Over voltage protection, Under voltage protection, Over-power protection, Short circuit protection, Over current protection, Over temperature protection
Standby efficiency
ErP 2013 (<0.45W @ 230 VAC, 45mA load on +5Vsb)
Sleep state compliance
C6/C7 compatible
Approvals & certifications
CE, FCC, KCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE



Connectors
ATX 24-pin
1
EPS/ATX12V
1
PCIe
4
SATA
6
Peripheral
3

Cable Configuration (length in mm between connectors)
ATX 24-pin
500
ATX 12V 4+4 pin
600
EPS12V 8-pin
N/A
PCIe 6+2 pin
550+150v
SATA
500+150+150
Peripheral
500+150+150

DC Output
3.3V
20A
5V
20A
3.3V and 5V combined
110W
12V
54.1A
-12V
0.3A
+5Vsb
3A
Total Power
650W
