Суич Cisco SF110D-05, 100Mbps, 5x ports

CISCO
SF110D-05

Standards
IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet

Cabling type
Category 5e or better

LED indicators
System/PWR, link/activity, 100M,*PoE, *mMax PoE, cable diagnostics, loop detection, gigabit,* mini-GBIC*
*if present

Ports
10/100/1000 Ethernet, with support for 802.3af PoE, power port for AC adapter or power cord

Power supply
SF110D-08: DC 12V, 500mA

Lock slot
Slot for Kensington lock

Physical Specifications
Physical dimensions (W x D x H)
3.65 x 1.06 x 3.57 inches (92.6 x 27 x 90.6 mm)

Weight
0.47 lb. (0.22 kg)

Ports
5 RJ-45 connectors for 10BASE-T/100BASE-TX

Performance

Switching capacity
1 Gbps

Forwarding capacity
0.74 mpps

Capabilities

Head-of-line (HOL) blocking
HOL blocking prevention

Jumbo frame
9216 bytes

Quality of service (QoS)
802.1p priority based, 4 hardware queues, priority queuing and weighted round-robin (WRR)

Loop detection
Helps discover loops in the network to avoid broadcast storms

Cable diagnostics
Quickly identify and troubleshoot network cable faults and/or shorts

Mounting and Physical Security

Mounting options
Desktop or rack mount

Physical security lock
Kensington lock slot

Environmental

Compliance/certifications
UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B*
*select models

Operating temperature
32° to 104°F (0° to 40°C)

Storage temperature
-4° to 158°F (-20° to 70°C)

Operating humidity
10% to 90%, relative, noncondensing

Storage humidity
5% to 90%, relative, noncondensing

System memory
128-MB RAM
128-MB Flash
