PoE сплитер TP-Link TL-POE10R

TL-POE10R
PoE Splitter

- IEEE 802.3af compliant
- Selectable power output
- Gigabit speed support
- Plug-and-Play, requires no configuration

HARDWARE FEATURES

Basic Function:
Compatible With IEEE 802.3af Compliant PSEs
Delivers Power Up To 100 Meters
Optional 12VDC, 9VDC or 5VDC Power Supply

Interface:
2 10/100/1000Mbps RJ45 Port
AUTO Negotiation/AUTO MDI/MDIX
1 48VDC POWER INPUT PORT

Network Media:
10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)

LED Indicator PWR
Dimensions ( W x D x H ) 80.8*54*24 mm
Power Supply 12VDC 1A, 9VDC 1A, 5VDC 2A

SOFTWARE FEATURES

Basic Function:
Compatible With IEEE 802.3af Compliant PSEs
Delivers Power Up To 100 Meters
Optional 12VDC, 9VDC or 5VDC Power Supply

OTHERS

Certification FCC, CE, RoHS
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.

Environment:
Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
