Ubiquiti USW-WAN
| Specification | Details |
|---|---|
| Dimensions | 442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7") |
| Port Layout | |
| – 1 GbE RJ45 | 1 port (1G/100M/10M) |
| – 10G SFP+ | 3 ports (10G/1G) |
| Redundancy | (2) AC inputs |
| Form Factor | Rack mount (1U) |
| Switching Capacity | 20 Gbps |
| Total Non-Blocking Throughput | 10 Gbps |
| Forwarding Rate | 15 Mpps |
| Max. Power Consumption | 13W |
| Power Method | (2) Universal input, 100–240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | (2) AC/DC internal, 36W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet |
| Weight | Without mounting brackets: 2.2 kg (4.85 lb) |
| With mounting brackets: 2.3 kg (5.1 lb) | |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| ESD/EMP Protection | Air: ± 16kV, Contact: ± 22kV |
| Ambient Operating Temperature | -5 to 40°C (23 to 104°F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| LED Indicators | Ethernet ✓, SFP+ ✓, System ✓ |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
| Application Requirements | UniFi Network Version 9.1.119 and later |
Виж още Суич Ubiquiti
Виж всички продукти Суич в категорията
Технически характеристики
| Брой портове: | 4 |
|---|---|
| Максимална скорост: | 1 Gbit/s |
| Стандарт: | Не е указано |
| Управляем: | Не е указано |
