Name: Суич TP-Link TL-SG2428P, 28 порта, 24x 10/100/1000 Mbps, 24x PoE+, 4x SFP
Brand: TP-Link
SKU: NTLHTPLINKTLSG2428P
Price: 333.78 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси Документация Вземи на изплащане

ХАРДУЕРНИ ХАРАКТЕРИСТИКИ
ПРОИЗВОДИТЕЛНОСТ
СОФТУЕРНИ ХАРАКТЕРИСТИКИ
MANAGEMENT
ДРУГИ
Стандарти и протоколи	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Интерфейс	• 24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) • 4× Gigabit SFP Slots
Мрежова медия	• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) • 1000BASE-X: MMF, SMF
Брой вентилатори	2
PoE+ Ports(RJ45)	• Standard: 802.3at/af compliant • PoE+ Ports: 24 Ports • Power Supply: 250 W
Размери (Ш x Д x В )	17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)
Монтаж	Rack Mountable
Макс. консумация на енергия	• 32.1 W (110 V/ 60 Hz with no PD connected) • 308.6 W (110 V/ 60 Hz with 250 W PD connected)
Max Heat Dissipation	109.53 BTU/h (with no PD connected) • 1052.94 BTU/h (with 250 W PD connected)
Bandwidth/Backplane	56 Gbps
Скорост на предаване на пакети данни	41.7 Mpps
Таблица на МАС адресите	8K
Packet Buffer Memory	4.1 Mbit
Jumbo кадър	9KB
Качество на услугата	• Support 802.1p CoS/DSCP priority • Support 8 priority queues • Queue scheduling: SP, WRR, SP+WRR • Port/Flow- based Rate Limiting • IPv6 QoS • Voice VLAN
L2 and L2+ Features	• Static Routing • DHCP Relay • DHCP Server • IGMP Snooping V1/V2/V3 • 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) • Spanning Tree STP/RSTP/MSTP • BPDU Filtering/Guard • TC/Root Protect • Loopback detection • 802.3x Flow Control • LLDP, LLDP-MED
VLAN	• Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) • MAC/Protocol-based VLAN
Access Control List	• L2–L4 package filtering • MAC ACL • IP ACL • Combined ACL • IPv6 ACL
Защита	• AAA • Port Security • DHCP Snooping • IP-MAC-Port Binding • IPv6-MAC-Port Binding • ARP Inspection • 802.1x and Radius Authentication • SSH v1/v2 • SSL v3/TLSv1.2 • Broadcast/Multicast/Unknown-unicast Storm Control • Dos Defend
IPv6	• Dual IPv4/IPv6 stack • Multicast Listener Discovery (MLD) Snooping • IPv6 neighbor discovery (ND) • Path maximum transmission unit (MTU) discovery • Internet Control Message Protocol (ICMP) version 6 • TCPv6/UDPv6
IPv6 Applications	• DHCPv6 Client • Ping6 • Tracert6 • Telnet (v6) • IPv6 SNMP • IPv6 SSH • IPv6 SSL • Http/Https • IPv6 TFTP
Omada App	Yes
Centralized Management	• Omada Cloud-Based Controller - Coming soon • Omada Hardware Controller (OC300) - Coming soon • Omada Hardware Controller (OC200) • Omada Software Controller
Cloud Access	Yes (Through OC200, Omada Software Controller) Yes (Through OC300, Omada Cloud-Based Controller) - Coming soon
Management Features	• Web-based GUI and CLI management • SNMP v1/v2c/v3,compatible with public MIBs and TP-Link private MIBs • RMON (1, 2, 3, 9 groups) • CPU Monitoring • Port Mirroring • Firmware Upgrade: TFTP & Web • System Diagnose: VCT • SYSLOG & Public MIBS • Dual Image • EEE
Сертификати	CE, FCC, RoHS
Съдържание на пакета	TL-SG2428P • Power Cord • Installation Guide • Rackmount Kit • Rubber Feet
Системни изисквания	Microsoft® Windows® XP, Vista™ or Windows 7, Windows 8, Windows 10, MAC® OS, NetWare®, UNIX® or Linux.
Околна среда	• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
