Точка за достъп Ubiquiti PowerBeam M5, Access Point, 150Mbps

Ubiquiti PowerBeam M5
PBE-M5-300


Описание

NanoBeam се използва като клиентско устройство за всеки един клиент в PtMP мрежата. Възможно е NanoBeam да се използва и за PtP връзки.

Характеристики

- иновативен дизайн
- високоскоростен процесор за превъзходна производителност
- възможност за монтаж на стълб или стена(включен кит)
- доказано потискане на шума


Specs

PBE-M5-300 System and Regulatory/Compliance

Processor Specs: Atheros MIPS 74Kc, 560 MHz
Memory: 64 MB DDR2, 8 MB Flash
Networking Interface: (1) 10/100 Ethernet Port
Wireless Approvals: FCC, IC, C
RoHS Compliance: Yes

PBE-M5-300 Physical/Electrical/Environmental

Dimensions: 325 x 325 x 256 mm
Weight: 1.203 kg
Power Supply: 24V, 0.5A PoE
Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
Max. Power Consumption: 6W
Gain: 22 dBi
Operating Frequency
Worldwide: 5170 - 5875 MHz
Wind Loading: 200.2 N @ 200 km/h
Wind Survivability: 200 km/h (125 mph)
LEDs: (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs: Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes: 5/8/10/20/30/40 MHz
Polarization: Dual Linear
Enclosure: Outdoor UV Stabilized Plastic
Mounting: Pole-Mount Kit Included
ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature: -40 to 70° C (-40 to 158° F)
Operating Humidity: 5 to 95% Noncondensing
Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test: IEC 68-2-6
Temperature Shock Test: IEC 68-2-14
UV Test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.
