Суич Tenda TEG1016D, 16x 10/100/1000M Base-T Ethernet ports

What It Does
TEG1016D, Tenda 16-Port Gigbit Rackmount Switch, adopts the most advanced Broadcom StrataConnect-series chip of high integrity, has 16 10/100/1000M Ethernet ports and is compatible with IEEE 802.3az standard. Special high reliability design supports for protecting the power adapter and ports from inducive lightning up to 6KV voltage; all provides an economical solution for network accessing layer with small-middle sized enterpries, schools and hotels, etc.

Main Features
● Compatible with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE802.3x
● and IEEE802.3ab 1000Base-T standards.
● Allows and assures packets to be forwarded by all ports at full wire speed.
● 16 10/100M/1000M auto-negotiated RJ45 ports.
● Support MDI/MDIX auto-negotiation.
● Support storage and forwarding.
● With inducive lightening protection towards the power adapter and ports, and
● enterprise-level design of 1U(thickness)-steel casing and 19-inch rack; With
● the help of hangers, it can be installed on the standard rack.
● Support 6000V lightning protection for power supply
● Support 4000V lightning protection for RJ45 port
● Support loop detection and prevention
● Support standard 13/19 inch rack-mountable
● Support Plug and Play，without any configuration

EEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
10Base-T: Cat. 3 UTP or better
Output: 20W
AC:100～240V
50/60Hz

280mm *179mm*44mm (L x W x H)

Store and Forward
32Gbps
8K

16*10/100/1000M Base-T Ethernet ports (Auto MDI/MDIX)

Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃
Operating Humidity: 10% ~ 90%RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing

TEG1224T, TEG1216T TEG1024G TEG1016G

FCC, CE, RoHS, WEEE
