Sharp 60006185 E759
Professional performance, affordable value
The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels.
Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the same remote control and device management for a consistent user experience. A robust metal back cover secures product longevity in commercial settings. Whether for presentations, retail signage, or corporate communication, the E9 Series gives you the professional edge without stretching your budget
| Category | Specification | Details |
|---|---|---|
| Display | Panel Technology | IPS with Direct LED backlights |
| Active Screen Area (W x H) [mm] | 1,650 x 928 | |
| Screen Size [inch/cm] | 74.5 / 189.3 | |
| Aspect Ratio | 16:9 | |
| Pixel Pitch [mm] | 0.430 | |
| Brightness [cd/m²] | 350 | |
| Contrast Ratio (typ.) | 1200:1 | |
| Viewing Angle [°] | 178 horizontal / 178 vertical (typ. at contrast ratio 10:1) | |
| Colour Depth [bn] | 1.07 (8bit + FRC) | |
| Response Time (typ.) [ms] | 8 | |
| Panel Refresh Rate [Hz] | 60 | |
| Haze Level [%] | Pro (25) | |
| Supported Orientation | Landscape; Portrait | |
| Resolution | Native Resolution | 3840 x 2160 |
| Supported Resolutions | 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576 | |
| Synchronisation Rate | Horizontal Frequency [kHz] | 31.5 - 135 |
| Vertical Frequency [Hz] | 24 - 75 | |
| Connectivity | Input Video Digital | 1 x USB-C (with HDCP, 15 W); 2 x HDMI |
| Input Audio Digital | 1 x USB-C; 2 x HDMI | |
| Input Control | 1 x LAN 100Mbit; 1 x RS232 | |
| Input Data | 1 x USB 2.0 (MediaPlayer); 1 x USB Type-C (5V/3A, power for external devices) | |
| Output Audio Analogue | 1 x 3.5 mm jack | |
| Remote Control | IR; RS-232C (9-pin D-sub) Input | |
| Connectivity Details | HDMI IN 1 | Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; ARC; CEC |
| HDMI IN 2 | Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC | |
| USB-A 1 | USB (2.0); 4.5 W; Peripherals; USB Storage | |
| USB-C 1 | Video Input; UHD (60 Hz); DP alt. 1.2; HDCP (2.2); Audio Input; USB 2.0; 15 W | |
| Audio Output (3.5 mm) | Audio Output; Line Out | |
| LAN 1 | 100 MBit/s | |
| RS-232C | 9600 bps | |
| Electrical | Power Consumption [W] | 170 (shipping) |
| Power Savings Mode [W] | < 0.5; < 2 (Networked Standby) | |
| Power Supply | 100-240 V AC; 50/60 Hz; internal | |
| Environmental Conditions | Operating Temperature [°C] | +0 to +40 |
| Operating Humidity [%] | 20 to 80 | |
| Storage Humidity [%] | 10 to 80 | |
| Storage Temperature [°C] | -20 to +60 | |
| Mechanical | Dimensions (W x H x D) [mm] | 1,680 x 959 x 58.5 |
| Weight [kg] | 24 | |
| Bezel Width [mm] | 12.9 | |
| VESA Mounting [mm] | 4 holes; 600 x 400 (FDMI); M8 | |
| Packaging Dimensions (W x H x D) [mm] | 1,875 x 1,130 x 186 | |
| Packaging Weight [kg] | 33 | |
| MediaPlayer | Supported File Storage / File System | USB 2.0 / FAT16, FAT32 |
| Supported Image Formats | JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640 | |
| Supported Video Formats | MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10 Pro) | |
| Supported Audio Formats | MP3 (MP3); max. bit-rate 320 kBit/s | |
| Available Options | Accessories | Feet (ST-86L); Trolley (L20PNSR780MEU); USB-C cable (USB-C 5M, USB-C 7M); Wall mount (SF680P, L20PNWALL90EU) |
| Regulatory | Safety and Ergonomics | CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI |
| Green Features | Energy Efficiency: 155 kWh/1000 h; Energy efficiency class: G; LED backlight | |
| Ecological Standards | EnergyStar 8.0 | |
| Additional Features | Special Characteristics | CEC Support; HDMI ARC; NaViSet Administrator 2 - free download; Powered USB-Port; Scheduler; USB Media Player |
| Colour Versions | Black Front Bezel, Black Back Cabinet | |
| Audio | Integrated Speakers | 10 W + 10 W |
| Shipping Content | Included | 2x AAA batteries; Display; Power Cable; Remote Control; Setup Manual |
| Warranty | Warranty | 3 years warranty incl. backlight |
| Operating Hours | Operating Hours | 16/7 |
| Remote Management | Software | NaViSet Administrator 2 |
