12x10G/Multi-Gig and 12xSFP+ (XSM4324) Managed Switch
- 12 10G/Multi-Gig ports, and 12 10GBASE-X SFP+ ports
- 240W internal power supply
- Half-width form factor enables one or two switches in a single rack space for redundant top-of-rack
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
- Layer 3 feature set includes static, policy-based, and dynamic routing
- NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
FOCUS ON THE EVENT
NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.
.png){kind=tracking}
| Category | Feature | Specification |
|---|---|---|
| Management Features | Switch type | Managed |
| Switch layer | L3 | |
| QoS support | Yes | |
| Web-based management | Yes | |
| ARP inspection | Yes | |
| Ports & Interfaces | RJ-45 ports quantity | 12 |
| RJ-45 port type | 10G Ethernet (100/1000/10000) | |
| 10G Ethernet (copper) ports | 12 | |
| SFP+ module slots | 12 | |
| Power connector | AC-in jack | |
| Network | Networking standards | IEEE 802.1D/Q/Qav/s/w/x, 802.3/ab/ad/ak/bz/u |
| 10G support | Yes | |
| Policy-based routing | Yes | |
| Full duplex | Yes | |
| 6to4 tunnel | Yes | |
| IPv4 routes | 512 | |
| IPv6 routes | 256 | |
| Spanning tree protocol | Yes | |
| Rate limiting | Yes | |
| Broadcast storm control | Yes | |
| Flow control support | Yes | |
| Link aggregation | Yes | |
| VLAN support | Yes | |
| Virtual LAN features | MAC-based, Private VLAN, Voice VLAN | |
| Number of VLANs | 4093 | |
| Data Transmission | Switching capacity | 480 Gbit/s |
| Throughput | 357.12 Mpps | |
| MAC address table | 16000 entries | |
| Store-and-forward | Yes | |
| Latency (1 Gbps) | 2.14 µs | |
| Latency (10 Gbps) | 2.29 µs | |
| Jumbo frames support | Yes | |
| Jumbo frames size | 12000 | |
| Packet buffer memory | 32 MB | |
| Security | DHCP features | Option 150/66/67, relay, server, snooping |
| Access Control List (ACL) | Yes | |
| ACL egress | 1023 | |
| ACL ingress | 511 | |
| IGMP proxy | Yes | |
| IGMP snooping | Yes | |
| Password protection | Yes | |
| DoS attack prevention | Yes | |
| Authentication type | RADIUS, TACACS+ | |
| Root protection | Yes | |
| Queue scheduling algorithms | SPQ, WRED | |
| Static port security | Yes | |
| MAC address filtering | Yes | |
| Loop protection | Yes | |
| BPDU filtering/protection | Yes | |
| Authentication | Guest VLAN, MAC-based authentication | |
| Multicast Features | Multicast support | Yes |
| MLD snooping | Yes | |
| Protocols | Management protocols | SNMP v1/v2/v3 |
| Routing protocols | OSPF, OSPFv2, OSPFv3, RIP-1, RIP-2 | |
| GVRP | Yes | |
| Design | Rack mounting | Yes |
| Stackable | Yes | |
| Form factor | 1U | |
| Product colour | Black | |
| LED indicators | Yes | |
| Airflow direction | Front-to-back | |
| Performance | Built-in processor | Yes |
| Processor model | ARM Cortex-A57 | |
| Processor frequency | 1800 MHz | |
| Memory type | DDR4-SDRAM | |
| Internal memory | 2048 MB | |
| Flash memory | 512 MB | |
| sFlow | Yes | |
| Power | Power source | AC |
| Power supply included | Yes | |
| Power consumption (typical) | 95.8 W | |
| PoE | Power over Ethernet (PoE) | No |
| Other Features | Power supply | 240 W |
| Operational Conditions | Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C | |
| Operating relative humidity (H-H) | 0 - 90% | |
| Storage relative humidity (H-H) | 0 - 95% | |
| Operating altitude | 0 - 3000 m | |
| Non-operating altitude | 0 - 3000 m | |
| Dimensions | Width | 220 mm |
| Depth | 400 mm | |
| Height | 43.2 mm | |
| Weight | 4.3 kg |
Виж още Суич Netgear
Виж всички продукти Суич в категорията
Документация
Product BriefТехнически характеристики
| Брой портове: | 24 |
|---|---|
| Максимална скорост: | 10 Gbit/s |
| Стандарт: | IEEE 802.3u |
| Управляем: | Да |
