TP-Link Omada SX6632YF
Omada 26-Port 10G Stackable L3 Managed Aggregation Switch with 6 25G Slots
- 26× 10G SFP+ slots and 6× 25G SFP28 slots
- 820 Gbps switching capacity
- Physical Stacking for built-in redundancy and performance
- L3 features: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay
- Security Strategies: ACL, Port Security, DoS Defend, 802.1X
- Highly Available with two field-replaceable power supplies*, VRRP, and ERPS
- Centralized cloud management via the Omada SDN controller
- Standalone management via web, CLI, SNMP, and RMON
The Omada SX6632YF is a true L3 managed switch with full fiber ports that offers L3 routing, swift 25 Gbps wired speed, stacking, and redundant power supplies, catering to convergence layer demands. It comes with 6× 25 Gbps SFP28 slots, 26× 10 Gbps SFP+ slots, and physical stacking. Integrated with robust security and comprehensive management features, this switch ensures reliable performance for SMB, enterprise, and ISP networks.
High-speed Connectivity and Powerful Stacking
6× 25 Gbps SFP28 slots and 26× 10 Gbps SFP+ slots provide up to 820 Gbps switching capacity per unit. Up to 8 units of physical stacking with up to 6560 Gbps switching capacity empowers the networking structure with built-in redundancy and performance.
Abundant Layer 3 Capabilities
Comes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server, and DHCP Relay are supported. PIM-DM multicast routing protocol guarantees efficient routing for multicast groups.
Highly Available
Internal fixed redundant power supplies* and VRRP make it an ideal choice for reliable networking architecture. ERPS supports rapid protection and recovery in a ring topology.
Enhanced Security Functions
Defend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.
Omada SDN
Integration into the Omada system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP).† The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers, providing 100% centralized cloud management—all controlled from a single interface.
Apart from the ability to be centrally managed via the web or the Omada app, SX6632YF is also easy to manage via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events.
Category | Specification |
---|---|
Hardware Features | |
Interface | - 6× 10/25G SFP28 Slots- 26× 10G SFP+ Slots- 2× USB 3.0 Ports- 1× RJ45 Console Port- 1× USB Type C Console Port- 1× RJ45 Management Port |
Fan Quantity | Four field-replaceable and hot-swappable fans |
Physical Security Lock | Yes (✓) |
Power Supply | Two field-replaceable and hot-swappable redundant power supplies (100–240 VAC, 50/60 Hz)Ships with one PSM550-AC module by default; second module sold separately |
Power Consumption | 86.7 W (110 V/60 Hz) |
Max Heat Dissipation | 295.85 BTU/hr (110 V/60 Hz) |
Dimensions (W x D x H) | 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm) |
Mounting | Rack Mountable |
Performance | |
Switching Capacity | 820 Gbps |
Packet Forwarding Rate | 610.1 Mpps |
Stacking | - Stacking Number: 8- Stacking Port: 25G SFP28- Stack Bandwidth: Up to 300 Gbps (6 stack ports) |
MAC Address Table | 128K |
Packet Buffer Memory | 8 MB |
Jumbo Frame | 9 KB |
Software Features | |
Quality of Service (QoS) | - Class of Service (8 Priority Queues)- Port Priority, IEEE 802.1p, DSCP- Schedule Modes: SP, WRR, SP+WRR- Bandwidth Control, Rate Limit, Storm Control- Voice VLAN, User-Defined OUI |
L3 Features | - Routing IP Interfaces, Static Routing, Host Route- RIP v1/v2, RIPng, OSPFv2/v3, VRRP, ECMP, ARP Proxy- DHCP Server, DHCP Relay, DHCPv6 Relay, DHCP Snooping, DHCPv6 Snooping- IGMP v1/v2/v3, Static Multicast Routing |
L2 & L2+ Features | - SPAN, RSPAN, Loopback Detection, Traffic Monitor- Static LAG, LACP 802.3ad- Static/Dynamic MAC, MAC Filtering/Flapping- STP (802.1d), RSTP (802.1w), MSTP (802.1s), Loop/Root/TC/BPDU Protection- ERPS- IGMP/MLD Snooping, L2 Multicast Table, Fast Leave- MVR, Static Multicast IP, Filtering |
Advanced Features | - Automatic Device Discovery†- Batch Config/Firmware Upgrading†- Intelligent Monitoring, Event Warnings†- Unified Configuration, Reboot Schedule† |
ISP Features | - 802.3ah Ethernet Link OAM- L2PT, DLDP, DDM, sFlow |
VLAN | - IEEE 802.1q, MAC VLAN, Protocol VLAN, VLAN VPN (QinQ)- Private VLAN, GARP/GVRP- Voice VLAN, Multicast VLAN, Management VLAN |
Security | - Port/MAC/IP Access Control, SSL, SSH- Port Security, Isolation, CPU Defend- Time Range (Definition, Periodic, Absolute, Holiday)- ACL (L2/3/4 ACL, Over VLAN/Port, Action)- IP+MAC+PORT+VID Binding, Manual Binding- ARP Scanning, DHCP/DHCPv6 Filter, Option 82- Dynamic ARP Inspection, IP/IPv6 Source Guard- ND Snooping/Filtering- DoS Defend- AAA (802.1X, RADIUS, TACACS+) |
Management | |
Omada App Support | Yes (requires Omada Hardware/Cloud-Based/Software Controller) |
Centralized Management | - Omada Cloud-Based Controller- Omada Hardware Controller- Omada Software Controller |
Cloud Access | Yes (requires Omada controller) |
Zero-Touch Provisioning | Yes (via Omada Cloud-Based Controller) |
Management Features | - Web GUI, CLI (via console port, telnet)- SNMPv1/v2c/v3 (Trap/Inform), RMON (1,2,3,9)- SDM Template, DHCP/BOOTP Client- LLDP/LLDP-MED- DHCP Auto Install, Dual Image/Config- CPU Monitoring, Cable Diagnostics- Password Recovery, SNTP, System Log |
Others | |
System Requirements | Microsoft® Windows® 98SE/NT/2000/XP/Vista/7/8/10/11, macOS, NetWare®, UNIX®, or Linux |
Виж още Суич TP-Link
Виж всички Суич в категорията
Брой портове: | 32 |
---|---|
Максимална скорост: | 25 Gbit/s |
Стандарт: | Не е указано |
Управляем: | Да |
