Specifications
Number of Ethernet ports
18
Number of fiber ports
2
Number of POE ports
16
Ports specification
16x 100BASE-T 802.3af / 802.3at PoE+, 2x RJ45 port (1 Gbps) or 2x SFP slot (1 Gbps) - Combo
UpLink
Maxiumum network link speed
1 Gbps
Network Link Type
Ethernet, Fiber
Management
Unmanaged
Number of LAN ports
18
Size
19"
Specialized
Industrial, Rack
Number of ports
2x 1GB BASE-T, LAN - 100 Mbps X16
Type of casing
Rack
Weatherproof rating
IP20
PoE support
Yes
PoE standards
802.3af, 802.3at
PoE power supply type
PoE, PoE+
Total budget for PoE
150 W
Maximum power per port
30 W
Buffer
4 Mbit
Bandwith
7.2 Gbps
MAC address table
16K
Power
150 W
Cooling
Active - fan
Power Requirements
100~240V AC
Power consumption
150 W
Surge protection
6 kV
Plug & Play
Yes
Work signal
LED
Wired standards
IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control)
Functions
Extend mode, Intelligent PoE port disconnection function, VLAN
Material
Metal
Software
No
ICT height
1 U
Length
208 mm
Width
320 mm
Height
45 mm
Weight
1.9 kg
Environment temperature
5 - 55 °C
Environment humidity
0 - 80 %
Виж още Суич Lanberg
Виж всички продукти Суич в категорията
Number of Ethernet ports
18
Number of fiber ports
2
Number of POE ports
16
Ports specification
16x 100BASE-T 802.3af / 802.3at PoE+, 2x RJ45 port (1 Gbps) or 2x SFP slot (1 Gbps) - Combo
UpLink
Maxiumum network link speed
1 Gbps
Network Link Type
Ethernet, Fiber
Management
Unmanaged
Number of LAN ports
18
Size
19"
Specialized
Industrial, Rack
Number of ports
2x 1GB BASE-T, LAN - 100 Mbps X16
Type of casing
Rack
Weatherproof rating
IP20
PoE support
Yes
PoE standards
802.3af, 802.3at
PoE power supply type
PoE, PoE+
Total budget for PoE
150 W
Maximum power per port
30 W
Buffer
4 Mbit
Bandwith
7.2 Gbps
MAC address table
16K
Power
150 W
Cooling
Active - fan
Power Requirements
100~240V AC
Power consumption
150 W
Surge protection
6 kV
Plug & Play
Yes
Work signal
LED
Wired standards
IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control)
Functions
Extend mode, Intelligent PoE port disconnection function, VLAN
Material
Metal
Software
No
ICT height
1 U
Length
208 mm
Width
320 mm
Height
45 mm
Weight
1.9 kg
Environment temperature
5 - 55 °C
Environment humidity
0 - 80 %
Виж още Суич Lanberg
Виж всички продукти Суич в категорията
Документация
Z30963-v2-EN-final.pdfТехнически характеристики
| Брой портове: | 18 |
|---|---|
| Максимална скорост: | 1 Gbit/s |
| Стандарт: | IEEE 802.3 at |
| Управляем: | Не |
