Tenda TEG1105PD
Tenda TEG1105PDTenda TEG1105PDTenda TEG1105PDempty image 3

Суич Tenda TEG1105PD, 5 порта, 5x 10/100/1000 Mbps PoE

id 236893 Код: NTLHTENDATEG1105PD

26.82 €

/

52.45 лв

Печат

Изпрати на приятел

ОписаниеХарактеристикиРевюта / Въпроси

TEG1105PD

5-Port Gigabit PD Switch With 4-Port PoE

Featuring low cost, high performance and plug & play, the PoE switch TEG1105PD is both a PSE and a PD, designed for such surveillance networking scenarios as roads in parks/communities, medium to large factories, and colleges. Small and delicate, it can be installed in an outdoor waterproof box easily. The switch provides four 10/100/1000 Mbps PoE OUT ports (ports 1 to 4) compliant with IEEE 802.3af and one 10/100/1000 Mbps PoE IN port (port 5) compliant with IEEE 802.3af/at. The maximum PoE output power of the whole switch is 30 W. The switch can supply power and transmit data to low-power APs and IP cameras through CAT5 cables, greatly reducing the cost of the network deployment. It is an ideal choice for wired networking in monitoring scenarios of middle to long distance.



Specifications:


Hardware

Network standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at

LED Indicator
1* Power LED indicator
4* PoE LED
indicators
5* Link/Act LED indicators

Interfaces
4*10/100/1000 Base-T Ethernet Ports(Data/PoE
UT)
1*10/100/1000 Base-T Ethernet Port(Data/PoE IN)

Transmission media
Recommended: CAT5/5e UTP or better

Fan quantity
N/A

Dimension
100.0 mm x 100.0 mm x 26.0 mm

Level of protection
Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV

Forwarding mode
Store-and-forward

Switch capacity
10 Gbps

Packet forwarding rate
7.44Mpps

Buffer
1 Mb

MAC address table
2K

Jombo frame
9K

PoE budget
Single port: AF: 15.4W

Power consumption
/

Input voltage
50-57V DC, 0.6A

Mounting
Desktop mounting: support
Wall mounting: non-support
Rack mounting : non-support

Environment
Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification
FCC、CE、RoHS







    Виж още Суич Tenda
    Виж всички продукти Суич в категорията
    Технически характеристики
    Брой портове:  5
    Максимална скорост:  1 Gbit/s
    Стандарт:  IEEE 802.3 at
    Управляем:  Не
