Technical Specifications

Compliance

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q
PCIe v1.0a standard
FCC (U.S. only) Class B
DOC (Canada) Class B
CE EN 55024, EN55022 Class B
VCCI Class II
UL 1950
CSA 950
EN 60950
CE
ACPI 1.1a
MicroSoft WHQL (Windows Hardware Quality Labs)

General Specifications

Communications: Intel 82572GI
Processor: 10/100/1000 Mbps, Half- and full-duplex
On-board memory: 48 KB
Data path: 1 lane (x1) PCI Express
Interrupt levels: Automatically configured
Cable Connector: One RJ-45
Bus Connector PCI Express
Distance and Wiring: Up to 328 feet/100 m with Category 5 (or better) twisted-pair cabling

Card Dimensions (without brackets):
(L x W) 5.1 x 2.7 in (12.95 x 6.8 cm)

Power and Environmental Specifications

Operating
Temperature 32° to 131° F (0° to 55° C )
Humidity 10% to 95% non-condensing

Non-operating
Temperature -40° to 85° F (-40° to 185° C)
Humidity -5% to 95%

Power requirement: 760mA @ 3.3V typical
Emissions Standards: FCC Class B, VCCI Class B, BSMI Class A, CISPR 22 Class B,
EN 55022 Class B, EN55024-1, ICES-003 Class B, MIC Class B, ACA Class B
Safety Compliant: UL, Canada UL, EN60950

Operating System Support

Microsoft:

Microsoft Windows Server 2003
Microsoft Windows Server 2003 Web Edition
Microsoft Windows Server 2003 Small Business Server
Microsoft certified miniport and teaming drivers
Microsoft Windows 2003 Standard (32 and x64)
Microsoft Windows 2003 Enterprise (32 and x64)

Linux:

Red Hat Enterprise Linux
SUSE Linux Enterprise Server
NOTE: For more information on Linux, please visit our Linux Certified and Supported matrix: http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html.
