Name: Суич Dahua S5436-24GF8GT4XF, 36 порта, 8x 10/100/1000Mbps RJ-45, 24x 10/100/1000Mbps SFP, 4x SFP+
Brand: Dahua
SKU: NTLHDAHUAS543624GF8GT4XF
Price: 2919.21 BGN
Availability: InStock

Описание Характеристики Ревюта / Въпроси

Dahua S5436-24GF8GT4XF

Category	Specification
Basic
Layer	Layer 2
Switching Capacity	144 Gbps
Packet Forwarding Rate	107.136 Mpps
Function Slots	Port 1–24: 24 × SFP 100/1000 Mbps Port 25–32: 8 × RJ-45 10/100/1000 Mbps Port 33–36: 4 × SFP+ 1/10 Gbps
Operating Temperature	–20 °C to +55 °C (–4 °F to +131 °F)
Operating Humidity	5%–95% RH, non-condensing
Storage Humidity	5%–95% RH, non-condensing
Power Supply	2 built-in power supplies: 100–240 VAC, 50/60 Hz, 2.5 A Max
Power Consumption	Idling: 23.8 WFull load: ≤ 100 W
Static Protection	Air discharge: 8 kVContact discharge: 6 kV
Lightning Protection	Common mode: 4 kVDifferential mode: 2 kV
Net Weight	3.8 kg (8.38 lb)
Gross Weight	5.3 kg (11.68 lb)
Product Dimensions	440 × 308.3 × 44 mm (17.32" × 12.14" × 1.73") (L × W × H)
Packaging Dimensions	528 × 412 × 112 mm (20.79" × 16.22" × 4.41") (L × W × H)
Installation	Rack mount; desktop mount
Hardware
Debugging	1 × Console port
Reset Button	1
Performance
Packet Buffer Size	16 Mbit
Jumbo Frame	12288 Byte
MAC Table Size	32K
Communication Standards	IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3z; IEEE 802.3ad
VLAN Number	4094
VLAN Interface	10
Features
Ethernet Loop Protection	STP / RSTP / ERPS
VLAN Function	Port-based VLAN
Link Aggregation	LACPStatic link aggregationDynamic link aggregation
Port Features	IEEE 802.3x flow controlUnknown unicast suppressionMulticast storm controlBroadcast storm control
IEEE 802.3x Flow Control	Yes
Multicast	IGMP Snooping
Reliability	LLDP
Routing	Static routing
DHCP Function	DHCP Client
Security	802.1XPort isolationRadiusHTTPS
QoS / ACL	SP / WRR queue scheduling802.1p and DSCP priority mappingPort speed limit
Equipment Management	Cloud managementWebSNMP V1/V2C/V3NTPLogsPing
