Мрежеста система Asus ZenWiFi AX Hybrid XP4 Mesh AX1800, 1800Mbps, 2.4GHz (574 Mbps)/ 5 GHz (1201 Mbps), Wireless AX, 2x LAN 10/100,1000bps 1x WAN 10/100/1000bps, 2 външни антени, 1 бр.

Asus ZenWiFi AX Hybrid XP4 Mesh AX1800





Whole-Home Coverage

The ZenWiFi AX Hybrid system includes a pair of ASUS AX1800 WiFi routers with built-in 1300 Mbps HomePlug AV2 powerline networking. It features unique technologies that give you superfast, reliable and secure WiFi connections – inside or outside your home!

Ideal For Overcoming Thick Walls
The ZenWiFi AX Hybrid combines WiFi and powerline technologies, providing the ideal solution for homes with thick or metal-reinforced walls that cause WiFi backhaul problems. Backhaul data for the mesh network can be sent via powerline over your home's electrical wiring, so home devices can connect at full AX1800 WiFi 6 speeds. The HomePlug AV2 MIMO standard is almost 2X faster* than the previous standard.













WiFi 6
True 8K Streaming

ZenWiFi AX Hybrid puts your WiFi into top gear! With a total bandwidth of up to of 1800 Mbps, it's up to 1.4X faster* than WiFi 5 routers **.

* Compatible WiFi 6 device required.
** The data compares speed of 2X2 11ax on 5GHz 80 MHz bandwidth with 1024QAM modulation to speed of 2x2 11ac on 5GHz 80MHz with 256QAM modulation.

Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
HomePlug AV2 MIMO
IEEE 1901
IEEE 1905.1
IEEE 802.3ab
IEEE 802.3z

Product Segment
AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps
AV1300 HomePlug AV2 MIMO : 1300 Mbps

AX technology
Yes

Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 4 (802.11n) TurboQAM : up to 400 Mbps
-----------------------------------
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps

Antenna
Internal antenna x 4

Processor
64bit 1.2 GHz quad-core processor

Memory
256 MB Flash
512 MB RAM

Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth

Operating Frequency
2.4G Hz / 5 GHz

Ports
RJ45 for Gigabit BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 2
USB 3.2 Gen 1 x 1
AC Power Jack with PLC x 1

Button
WPS/PLC Combo Button, Reset Button

LED Indicator
Power & Status Combo LED x 1

Power Supply
AC Input : 110V~240V(50~60Hz)

Package content
‧Router (XP4)
‧RJ45 Ethernet cable
‧Power core
‧Quick start guide
‧Warranty Card

Remark
Content may vary in different regions and packages.

AiMesh
AiMesh
Primary AiMesh router
AiMesh node

Router APP
ASUS Router APP

Alexa
Support Alexa skill

AiProtection
AiProtection Pro
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking

Parental Control
Parental Control
Parental Control Customized Internet schedule
Maximum Parental Control profile : Max 16 rules
Maximum Parental Control content filter rule : Max 16 rules

Traffic Control
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule : Max 32 rules
Traditional QoS
Maximum Traditional QoS rule : Max 32 rules
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Website history

Wireless
IPv6
Wi-Fi Encryption : WPA3-Personal, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPS support
UTF-8 SSID
Guest Network
Maximum Guest Network rule : Max 6 rules
Guest Network Connection time limit
Guest Network Encryption : Max 6 rules
WPS
WiFi MAC address filter
Maximum MAC filters : Max 64 rules
Wireless scheduler
Airtime fairness
RADIUS Server
Universal beamforming
Explicit beamforming

WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN
3G/4G LTE dongle
Android tethering
Port forwarding
Port triggering
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough
Let's Encrypt

LAN
DHCP Server
IGMP snooping
IPTV
Manually assign IP address
Maximum manually assign IP address rule : Max 64 rules

VPN
Instant Guard
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP

USB application
File System : FS_Tuxera_HFS+, FS_Tuxera_NTFS, FS_Tuxera_vFAT, FS_ext2, FS_ext3, FS_ext4
HDD hibernation
Safely Remove disk
AiCloud
Download master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges

Administration
Operating mode : Wireless router mode,Range extender mode,Access point mode,Media bridge mode
Free OS upgrade
Firewall
Maximum Firewall keyword filter : Max 64 rules
Maximum Firewall network service filter : Max 32 rules
Maximum Firewall URL filter : Max 64 rules
Wake on LAN (WOL)
SSH
Configuration backup and restore
Diagnosis tools
Feedback system
System log
