Cisco SFE2010P-G5 48-Port 10/100 Суич, with PoE

Сигурност IEEE 802.1X - RADIUS authentication, MD5 hash; guest VLAN; single/multiple host mode; ACLs: Drop or rate limit based on source and destination MAC or IP address, protocol, port, VLAN, DSCP/IP precedence, TCP/ User Datagram Protocol (UDP)
Захранване Redundant; Cisco RPS1000 380W Redundant Power Supply Unit
MAC адреси 8000 MAC address table size
Управление Built-in web user interface for easy browser-based configuration (HTTP/HTTPS); SNMP versions 1, 2c, and 3 with support for traps; Embedded RMON software agent supports 4 RMON groups; Traceroute; single IP management; SSL security for web user interface
Памет (Flash, RAM) -
VLAN (брой, стандарти) Number of VLANs: 256 active VLANs (4096 range); Port-based and 802.1Q tag-based VLANs, protocol-based VLAN, management VLAN, multicast TV VLAN, PVE, GVRP
Размери, mm 440 x 375 x 44 mm, 1U Height
Stackable Up to 192 ports in a stack; Hot insertion and removal; Ring and chain stacking options; Master and backup master for resilient stack control; Auto-numbering or manual configuration of units in stack
Суич, тип Fixed Port
Общ брой портове 50
Основни портове, тип 48x10/100Base-TX
Power Over Ethernet (PoE) IEEE 802.3af PoE delivered over any of the forty-eight 10/100 ports; Maximum power of 15.4W to a Fast Ethernet port - 360W total available to all Fast Ethernet ports with regular AC power, 280W total available with a redundant power supply unit
Uplink портове 2x10/100/1000Base-T, 2xSFP
Свободни (10GB) слотове No
Fans yes
Routing Layer 3 Lite
Капацитет за маршрутизиране/превключване, Gbps 17.6 Gbps
Пропускателна способност, Mpps 13 Mpps
QoS Priority levels: 4 hardware queues; Scheduling: Priority queuing and weighted round-robin (WRR); Class of service: Port based; 802.1p VLAN priority based; IPv4/v6 IP precedence/ToS/DSCP based; DiffServ; classification and re-marking ACLs; Rate limiting
L2 мреживи стандарти IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
L3 мрежови стандарти Static routing; classless interdomain routing (CIDR); 60 static routes; IPv4 and IPv6; forwarding in silicon - wire-speed forwarding of Layer 3 traffic
IPv6 functionality IPv6 over Ethernet, dual stack, IPv6 over IPv4 network with Intra-Site Automatic Tunnel Addressing Protocol (ISATAP) tunnel, IPv6 neighbor discovery, IPv6 stateless address configuration, maximum transmission unit (MTU) discovery, WEB, SSL, Telnet, Ping
