Ubiquiti PowerBeam AC ISO
PBE-5AC-400-ISO
Specifications
Dimensions
459 x 459 x 261 mm (18.07 x 18.07 x 10.28")
Weight
3.22 kg (7.10 lb)
Power Supply
24V, 0.5A Gigabit PoE
Power Method
Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range
20-26VDC
Max. Power Consumption
8.5W
Operating Frequency
Worldwide
5150 - 5875 MHz
USA: U-NII-1
5150 - 5250 MHz*
USA: U-NII-2A
5250 - 5350 MHz*
USA: U-NII-2C
5470 - 5725 MHz*
USA: U-NII-3
5725 - 5850 MHz
Gain
25 dBi
Networking Interface
(1) 10/100/1000 Ethernet Port
Processor Specs
Atheros MIPS 74Kc, 560 MHz
Memory
64 MB DDR2, 16 MB Flash
LEDs
(1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs
Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes
PtP Mode
10/20/30/40/50/60/80 MHz
PtMP Mode
10/20/30/40 MHz
Max. VSWR
1.5:1
Built-In Mechanical Downtilt
± 20°
Polarization
Dual Linear
Enclosure
Outdoor UV Stabilized Plastic
Mounting
Pole-Mount Kit Included
Wind Loading
559 N @ 200 km/h (125.7 lbf @ 125 mph)
Wind Survivability
200 km/h (125 mph)
ESD/EMP Protection
Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature
-40 to 70° C (-40 to 158° F)
Operating Humidity
5 to 95% Noncondensing
Wireless Approvals
FCC, IC, CE
RoHS Compliance
Yes
Salt Fog Test
IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test
IEC 68-2-6
Temperature Shock Test
IEC 68-2-14
UV Test
IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test
ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
Виж още Аксеспойнт/Репитер Безжични Ubiquiti
Виж всички Аксеспойнт/Репитер Безжични в категорията
PBE-5AC-400-ISO
Specifications
Dimensions
459 x 459 x 261 mm (18.07 x 18.07 x 10.28")
Weight
3.22 kg (7.10 lb)
Power Supply
24V, 0.5A Gigabit PoE
Power Method
Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range
20-26VDC
Max. Power Consumption
8.5W
Operating Frequency
Worldwide
5150 - 5875 MHz
USA: U-NII-1
5150 - 5250 MHz*
USA: U-NII-2A
5250 - 5350 MHz*
USA: U-NII-2C
5470 - 5725 MHz*
USA: U-NII-3
5725 - 5850 MHz
Gain
25 dBi
Networking Interface
(1) 10/100/1000 Ethernet Port
Processor Specs
Atheros MIPS 74Kc, 560 MHz
Memory
64 MB DDR2, 16 MB Flash
LEDs
(1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs
Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes
PtP Mode
10/20/30/40/50/60/80 MHz
PtMP Mode
10/20/30/40 MHz
Max. VSWR
1.5:1
Built-In Mechanical Downtilt
± 20°
Polarization
Dual Linear
Enclosure
Outdoor UV Stabilized Plastic
Mounting
Pole-Mount Kit Included
Wind Loading
559 N @ 200 km/h (125.7 lbf @ 125 mph)
Wind Survivability
200 km/h (125 mph)
ESD/EMP Protection
Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature
-40 to 70° C (-40 to 158° F)
Operating Humidity
5 to 95% Noncondensing
Wireless Approvals
FCC, IC, CE
RoHS Compliance
Yes
Salt Fog Test
IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test
IEC 68-2-6
Temperature Shock Test
IEC 68-2-14
UV Test
IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test
ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
Виж още Аксеспойнт/Репитер Безжични Ubiquiti
Виж всички Аксеспойнт/Репитер Безжични в категорията
Технически характеристики
| Тип: | Аксес пойнт |
|---|---|
| Монтаж: | За външен монтаж |
| Безжична скорост: | 450 Mbps |
| Wi-Fi Стандарт: | Wi-Fi 5 (802.11ac) |
| Честота: | 5 GHz |
| Антени: | 1 Външна |
| dBi на антена/и: | 25 |
| PoE: | In |
| Интерфейс: | 1x 1000 |
| Други: | Няма |
