NBE-5AC-19 е последно поколение NanoBeam AC клиентско оборудване подходящо за PTP и PtMP връзки.
Повишена шумова изолация
Иновативна механична конструкция
Високоскоростен процесор
PoE гигабитов мрежови порт
Включен монтажен кит
System and Regulatory/Compliance
Processor Specs: Atheros MIPS 74Kc, 720 MHz
Memory: 128 MB DDR2, 8 MB Flash
Networking Interface: (1) 10/100/1000 Ethernet Port
Wireless Approvals: FCC, IC, CE
RoHS Compliance: Yes
Physical/Electrical/Environmental
Dimensions: 189 x 189 x 125 mm (7.44 x 7.44 x 4.92 in)
Weight: 0.530 kg (1.17 lb)
Power Supply: 24V, 0.5A Gigabit PoE
Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range: 20-26VDC
Max. Power Consumption: 8W
Gain: 19 dBi
Operating Frequency
Worldwide 5150 - 5875 MHz
USA 5725 - 5850 MHz
Wind Loading: 45.4 N @ 200 km/h (10.2 lbf @ 125 mph)
Wind Survivability: 200 km/h (125 mph)
LEDs: (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs: Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes
PtP Mode 10/20/30/40/50/60/80 MHz
PtMP Mode 10/20/30/40 MHz
Polarization: Dual Linear
Enclosure: Outdoor UV Stabilized Plastic
Mounting: Pole-Mount (Kit Included), Wall-Mount
ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature: -40 to 70° C (-40 to 158° F)
Operating Humidity: 5 to 95% Noncondensing
Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test: IEC 68-2-6
Temperature Shock Test: IEC 68-2-14
UV Test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
https://www.ubnt.com/airmax/nanobeam-ac/
https://dl.ubnt.com/datasheets/NanoBeam_ac/NanoBeam_ac_DS.pdf
Виж още Аксеспойнт/Репитер Безжични Ubiquiti
Виж всички Аксеспойнт/Репитер Безжични в категорията
Повишена шумова изолация
Иновативна механична конструкция
Високоскоростен процесор
PoE гигабитов мрежови порт
Включен монтажен кит
System and Regulatory/Compliance
Processor Specs: Atheros MIPS 74Kc, 720 MHz
Memory: 128 MB DDR2, 8 MB Flash
Networking Interface: (1) 10/100/1000 Ethernet Port
Wireless Approvals: FCC, IC, CE
RoHS Compliance: Yes
Physical/Electrical/Environmental
Dimensions: 189 x 189 x 125 mm (7.44 x 7.44 x 4.92 in)
Weight: 0.530 kg (1.17 lb)
Power Supply: 24V, 0.5A Gigabit PoE
Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range: 20-26VDC
Max. Power Consumption: 8W
Gain: 19 dBi
Operating Frequency
Worldwide 5150 - 5875 MHz
USA 5725 - 5850 MHz
Wind Loading: 45.4 N @ 200 km/h (10.2 lbf @ 125 mph)
Wind Survivability: 200 km/h (125 mph)
LEDs: (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs: Software-Adjustable to Correspond to Custom RSSI Levels
Channel Sizes
PtP Mode 10/20/30/40/50/60/80 MHz
PtMP Mode 10/20/30/40 MHz
Polarization: Dual Linear
Enclosure: Outdoor UV Stabilized Plastic
Mounting: Pole-Mount (Kit Included), Wall-Mount
ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature: -40 to 70° C (-40 to 158° F)
Operating Humidity: 5 to 95% Noncondensing
Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test: IEC 68-2-6
Temperature Shock Test: IEC 68-2-14
UV Test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
https://www.ubnt.com/airmax/nanobeam-ac/
https://dl.ubnt.com/datasheets/NanoBeam_ac/NanoBeam_ac_DS.pdf
Виж още Аксеспойнт/Репитер Безжични Ubiquiti
Виж всички Аксеспойнт/Репитер Безжични в категорията
Документация
Официален сайт на производителя
pdfТехнически характеристики
| Тип: | Аксес пойнт |
|---|---|
| Монтаж: | За външен монтаж |
| Безжична скорост: | 450 Mbps |
| Wi-Fi Стандарт: | Wi-Fi 5 (802.11ac) |
| Честота: | 5 GHz |
| Антени: | 1 Външна |
| dBi на антена/и: | 19 |
| PoE: | In |
| Интерфейс: | 1x 1000 |
| Други: | До 15+км |
