HARDWARE FEATURES
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
Interface 16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity Fanless
Dimensions ( W x D x H ) 17.3*7.1*1.7 in. (440*180*44 mm)
Power Consumption Maximum: 13.3W (220V/50Hz)
Power Supply 100-240VAC, 50/60Hz
PERFORMANCE
Switching Capacity 32Gbps
MAC Address Table 8K
Packet Forwarding Rate 23.8Mpps
Jumbo Frame 10KB
Green Technology Innovative energy-efficient technology saves power up to 15%
Transfer Method Store-and-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents
16-Port Gigabit Rackmount Switch
Power Cord
Installation Guide
Rackmount Kits
Rubber Feet
System Requirements
Microsoft® Windows® XP, Vista™, Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux.
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~70℃ (-40℉~158℉);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
Виж още Суич TP-Link
Виж всички продукти Суич в категорията
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
Interface 16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity Fanless
Dimensions ( W x D x H ) 17.3*7.1*1.7 in. (440*180*44 mm)
Power Consumption Maximum: 13.3W (220V/50Hz)
Power Supply 100-240VAC, 50/60Hz
PERFORMANCE
Switching Capacity 32Gbps
MAC Address Table 8K
Packet Forwarding Rate 23.8Mpps
Jumbo Frame 10KB
Green Technology Innovative energy-efficient technology saves power up to 15%
Transfer Method Store-and-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents
16-Port Gigabit Rackmount Switch
Power Cord
Installation Guide
Rackmount Kits
Rubber Feet
System Requirements
Microsoft® Windows® XP, Vista™, Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux.
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~70℃ (-40℉~158℉);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
Виж още Суич TP-Link
Виж всички продукти Суич в категорията
Документация
TP-Link TL-SG1016 - switch - 16 ports - rack-mountable User manual- TP-Link TL-SG1016 - switch - 16 ports - rack-mountable Brochure
- TP-Link TL-SG1016 - switch - 16 ports - rack-mountable Brochure
- TP-Link TL-SG1016 - switch - 16 ports - rack-mountable User manual
- Product Brochure
- User manual
- Product Brochure
- User manual
Технически характеристики
| Брой портове: | 16 |
|---|---|
| Максимална скорост: | 1 Gbit/s |
| Стандарт: | 802.3ab |
| Управляем: | Не |
