Дънна платка MSI B840M Gaming Plus WIFI6E, B840, AM5, DDR5, PCI-E 4.0 (HDMI), 4x SATA 6Gb/s, 2x M.2 slots, 1x USB 3.2 Gen 1 Type-C, Bluetooth 5.3, Micro ATX

CPU Support
Supports AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors

CPU Socket
AMD Socket AM5

Chipset
AMD B840 Chipset

Expansion slot
1x PCIe 4.0 x16 slot
1x PCIe 3.0 x4 slot

Display Interface
Support 4K@60Hz as specified in HDMI 2.1, DisplayPort 1.4 – Requires Processor Graphics

Memory
Support 4 DIMMs, Dual Channel DDR5 - 8000+ MT/s (OC)
Ryzen™ 9000 Series Processors max. overclocking frequency:
• 1DPC 1R Max speed up to 8000+ MT/s
• 1DPC 2R Max speed up to 6400+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 5600+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only*

Storage
2 x M.2 Gen4 x4 64Gbps slots
4 x SATA 6Gbps ports

RAID
Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

USB ports
2 x USB 10Gbps (1 Type-A + 1 Type-C)
5 x USB 5Gbps (4 Type-A + 1 Type-C)
8 x USB 2.0

LAN Realtek
8125D 2.5G LAN

WIFI / BT
Wi-Fi 6E module, Bluetooth 5.3

Audio
Realtek ALC897 Codec
7.1-Channel High Definition Audio

PCB Info
mATX
243.84mm x 243.84mm
