Specifications
Number of Ethernet ports
26
Number of fiber ports
2
Number of console ports
0
Number of POE ports
24
Ports specification
24x 100BASE-T 802.3af/802.3at PoE+, 2x RJ45 port (1 Gbps) or 2x SFP slot (1 Gbps) - Combo UpLink
Maxiumum network link speed
1 Gbps
Network Link Type
Ethernet, Fiber
Management
Unmanaged
Size
19"
Specialized
Industrial, Rack
Type of casing
Rack
Weatherproof rating
IP20
Chipset
Realtek - RTL8326B
PoE support
Yes
PoE standards
802.3af, 802.3at
PoE power supply type
PoE, PoE+
Power
370 W
Total budget for PoE
360 W
Maximum power per port
30 W
Buffer
4 Mbit
Bandwith
8.8 Gbps
MAC address table
8K
Cooling
Fan, Vents
Power Requirements
100~240V AC
Power consumption
0 W
Surge protection
4 kV
Compatible with Jumbo Frames
9216 (B)
Packets per second
6.55 pps
IGMP snooping
No
IGMP proxy
No
Plug & Play
Yes
Command line
No
STP loop protection
Not
Work signal
LED
Wired standards
IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z 1000Base-LX/SX
Functions
Extend mode, Intelligent PoE port disconnection function, VLAN
Material
Metal
Software
No
ICT height
1 U
Length
207 mm
Width
320 mm
Height
44 mm
Weight
2.7 kg
Environment temperature
5 - 55 °C
Environment humidity
0 - 80 %
Виж още Суич Lanberg
Виж всички продукти Суич в категорията
Number of Ethernet ports
26
Number of fiber ports
2
Number of console ports
0
Number of POE ports
24
Ports specification
24x 100BASE-T 802.3af/802.3at PoE+, 2x RJ45 port (1 Gbps) or 2x SFP slot (1 Gbps) - Combo UpLink
Maxiumum network link speed
1 Gbps
Network Link Type
Ethernet, Fiber
Management
Unmanaged
Size
19"
Specialized
Industrial, Rack
Type of casing
Rack
Weatherproof rating
IP20
Chipset
Realtek - RTL8326B
PoE support
Yes
PoE standards
802.3af, 802.3at
PoE power supply type
PoE, PoE+
Power
370 W
Total budget for PoE
360 W
Maximum power per port
30 W
Buffer
4 Mbit
Bandwith
8.8 Gbps
MAC address table
8K
Cooling
Fan, Vents
Power Requirements
100~240V AC
Power consumption
0 W
Surge protection
4 kV
Compatible with Jumbo Frames
9216 (B)
Packets per second
6.55 pps
IGMP snooping
No
IGMP proxy
No
Plug & Play
Yes
Command line
No
STP loop protection
Not
Work signal
LED
Wired standards
IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z 1000Base-LX/SX
Functions
Extend mode, Intelligent PoE port disconnection function, VLAN
Material
Metal
Software
No
ICT height
1 U
Length
207 mm
Width
320 mm
Height
44 mm
Weight
2.7 kg
Environment temperature
5 - 55 °C
Environment humidity
0 - 80 %
Виж още Суич Lanberg
Виж всички продукти Суич в категорията
Документация
Z30966-v2-EN-final.pdfТехнически характеристики
| Брой портове: | 26 |
|---|---|
| Максимална скорост: | 1 Gbit/s |
| Стандарт: | IEEE 802.3 at |
| Управляем: | Не |
