Name: Суич Dahua CS4010-8ET-60, 1000 Mbps, 10 порта, 8x 10/100Mbps POE, 2x 10/100/1000Mbps RJ45 (uplink)
Brand: Dahua
SKU: NTLHDAHUADHCS40108ET60
Availability: OutOfStock

Описание Характеристики Ревюта / Въпроси

10-Port Cloud Managed Desktop Switch with 8-Port PoE

> Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab standards.

> Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE power supply standards.

> Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE.

> A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof.

Technical Specifications

Basic

Layer	Layer 2
Switching Capacity	4.8 Gbps
Packet Forwarding Rate	3.57 Mpps
Description of Function Slots	Port 1-8: 8 × RJ-45 10/100 Mbps (PoE); Port 9-10: 2 × RJ-45 10/100/1000 Mbps (uplink)
PoE Power	Port 1 ≤ 60 W, Port 2-8 ≤ 30 W, total ≤ 60 W
Operating Temperature	–10 °C to +55 °C (+14 °F to +131 °F)
Operating Humidity	5% –95% (RH), non-condensing
Power Consumption	Idling: ≤3 W; Full load: 65 W
Power Supply	External power supply: 53 VDC, 1.226 A
Statics Protection	Air discharge: 8 kV; Contact discharge: 6 kV
Lightning Protection	Common mode: 4 kV; Differential mode: 2 kV
Net Weight	0.28 kg (0.64 lb)
Product Dimensions	130 mm × 90 mm × 26 mm (5.11" × 3.54" × 1.02") (L × W × H)

Hardware

PoE	Yes
Reset Button	1
Storage Temperature	–40 °C to +70 °C (–40 °F to +158 °F)
Storage Humidity	5%–95% (RH), non-condensing

Performance

MTBF	232.62 years
Packet Buffer Size	4 Mbit
Jumbo Frame	9216 Byte
MAC Table Size	8K
VLAN Number	32
Communication Standard	IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab

Feature

PoE Protocol	IEEE802.3af; IEEE802.3at; Hi-PoE
PoE Power Consumption Management	Yes
PoE Pin Assignment	1,2,4,5（V+）,3,6,7,8（V-）
Long Distance PoE Transmission	Yes
VLAN Function	Port-based VLAN
IEEE 802.3x Flow Control	Yes
DHCP Function	DHCP Client
Equipment Management	Web management; App management
