D-LINK GO-SW-5G
• Switching Fabric
10Gbps
• Standards
IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twistedpair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet (EEE)
• Protocol
CSMA/CD
• Data Transfer Rates
Ethernet:
10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit Ethernet:
2000 Mbps (full duplex)
• Topology
Star
• Network Cables
10BASE-T:
UTP CAT 3, 4, 5/5e (100 m max.)
EIA/TIA-586 100-ohm STP (100 m max.)
100BASE-TX, 1000BASE-T:
UTP CAT 5/5e (100 m max.)
EIA/TIA-568 100-ohm STP (100 m max.)
• Media Interface Exchange
Auto MDI/MDIX adjustment for all ports
• LED Indicators
Per port: Link/Activity/Speed
Per device: Power
• Transmission Method
Store-and-forward
• MAC Address Table
2K
• MAC Address Learning
Automatic update
• Packet Filtering/Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port
• RAM Buffer
128KB per device
• Jumbo Frames
9,216 Bytes
• DC Input
External 5 V/1 A Level "V" Power Adapter
• Power Consumption
DC input: 1.67 watts
AC input: 2.7 watts
• MTBF
815,700 hours
• Operating Temperature
0 to 40 C
• Storage Temperature
-10 to 70 C
• Operating Humidity
10% to 90% RH non-condensing
• Storage Humidity
5% to 90% RH non-condensing
• Dimensions
97 x 79 x 28 mm
• Weight
105 grams
• Certifications
FCC Class B
ICES-003 Class B
CE Class B
C-Tick Class B
VCCI Class B
cUL/UL
CCC
Anatel
LVD
Виж още Суич D-Link
Виж всички продукти Суич в категорията
| Брой портове: | 5 |
|---|---|
| Максимална скорост: | 1 Gbit/s |
| Стандарт: | 802.3ab |
| Управляем: | Не |
