24-GbE PoE Switch with 2 Uplink GbE and 2 Uplink SFP
A rack-mounted 26-GbE, 2-SFP PoE switch with a 300W power supply and a silent cooling system.
- 24× GbE with 802.3at/af PoE
- 2× Uplink GbE + 2× Uplink SFP
- 300W Power Supply
- Default/Extend Modes
- Watchdog under Extend Mode
- Desktop, Rack-Mount
- 320×207×44 mm (12.6×8.15×1.73″)
| Specification | Details |
|---|---|
| Model Version | GS1026PS2 1.0 |
| 1.25G SFP Slots | 2 |
| Gigabit RJ45 Ports | 26 |
| Gigabit RJ45 PoE Ports | #1~#24 |
| Max Power on a Single PoE Port | 30W |
| PoE Port Notes | The PoE ports comply with IEEE 802.3at/af standards. |
| Extend Mode Ports | #17~#24 |
| Power | — |
| DIP Mode (SW) | — |
| PoE Status of Each PoE Port | — |
| Link/ACT of Each Ethernet Port | — |
| PoE Max Status | — |
| Default/Extend DIP switch | — |
| PoE LED Toggle | — |
| Physical Buttons Note | The PoE Watchdog is on under the Extend mode and will attempt to reboot the plugged-in but inactive client. |
| Max Copper Speed and Distance | Cat. 3 or higher cable: 100 meters at 10 MbpsCat. 5 or higher cable: 100 meters at 100 MbpsCat. 5e or higher cable: 100 meters at GigabitCat. 5e or higher cable: 250 meters at 10 Mbps |
| Copper Speed and Distance Note | 250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated. |
| Optical Spec and Distance | Depends on the Installed Optical Module |
| MAC Address Table | 8192 |
| Max Switching Capacity | 56 Gbps |
| Max Forwarding Rate | 41.664 Mpps |
| Packet Buffer | 3 Mbit |
| Power Input Type | AC Inlet |
| Power Methods | AC |
| Power Input | 100-240V~ 50/60Hz |
| Power Supply | 300W |
| Max Power Excluding PoE | 20W |
| 802.3 Protocols | 802.3i 10BASE-T802.3u 100BASE-TX802.3ab 1000BASE-T802.3z 1000BASE-X802.3x Flow Control802.3af PoE802.3at PoE |
| Grounding Methods | Three-Prong Plug |
| EMS | IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV |
| Environment | Operating Temperature: 0~40 ℃ (32~104 ℉)Storage Temperature: -40~70℃ (-40~158 ℉)Operating Humidity: 10~90% non-condensingStorage Humidity: 10~95% non-condensing |
| Dimension | 320×207×44 mm12.6×8.15×1.73 inches |
| Product Weight | 1986 g (70.05 oz.) |
| Casing Material | Metal |
| Installation | DesktopRackmount via Brackets |
| Retail Package Dimension | 370×290×85 mm14.57×11.42×3.35 inches |
| Retail Package Weight | EU: 2534 g (89.38 oz.) |
