Thermalright SP-750
| AC input | 100-240V ~ ,11-5.5A,47-63Hz |
| DC output | +3.3V +5V | +12V | -12V | +5VSB |
| Max output current | 20A 20A | 62.5A | 0.3A | 2.5A |
| Max output power | 130W | 750W | 3.6W | 12.5W |
Cables
M/B type: MB 20+4 PIN 600MM x1
CPU type: CPU 4+4 Pin 650MM x2
PCI-E type: PCI-E 6+2 PIN 650MM x3, 12V-2X6 type PCI-E 5.1 600MM x1
SATA + PATA type: 450mm+150mm+150mm+150mm x2, 500mm+150mm+150mm x1
Features
80 Plus Platinum
Fully compatible with Intel ATX 3.1 specification, up to 200% power excursion
Ready for the PCI-E gen 5.1 graphics cards, 12V-2x6 cable support
LLC resonance + DC-DC circuit design
105°C temperature-resistant japanese main capacitor / All-japanese electrolytic capacitors
Full modular cables
Smart fan start stop
100-240V full voltage design
Technical Specs
Dimension: L150 mm x W140 mm x H85 mm±2 mm
Wattage：750W
Efficiency：80 PLUS Platinum
Modular：Full-Modular
Input Voltage：100-240Vac
Input Current：11-5.5A
Input Frequency：47-63Hz
Fan Size：120 mm
Operating Temperature：0-40°C
MTBF：>100K Hours
Protections：OPP/OVP/OTP/OCP/SCP/UVP
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Захранвания Настолни компютри Thermalright
Виж всички Захранвания Настолни компютри в категорията
| Изходна мощност: | 750 W |
|---|---|
| Модулен блок: | Да |
| Форм фактор: | ATX |
