Захранване MSI PRO A850PL PCIE5, 850W, Active PFC, 80 Plus Platinum, 120mm вентилатор

Reliable Connector Design:
The power supply features the 12V-2x6 (H++) connector, design with an optimized structure that complies with the PCIe CEM 5.1standard. The ensures enhanced reliability and safety. It is capable of delivering up to 450W of power, making it suitable for even the most demanding high-end graphics cards.

Platinum Efficiency Certification:
The efficiency of your power supply significantly impacts overall power consumption. The Platinum certification stands out as a reliable benchmark for energy efficiency, ensuring that your power supply delivers lower energy consumption and operates at higher efficiency levels.

105°C Main Capacitor:
Aiming for superior product quality and performance stability, this power supply features 105°C main capacitors for long-term use reliability.

Built for Maximum Safety:
The power supply's cables, from the internal copper wires to the external high-density braided cover, are fully UL certified, ensuring superior safety and durability.


Specifications

Efficiency Rating
80 PLUS Platinum (up to 92%)

Modular
Fully Modular

Fan Size
120 mm

Fan Bearing
Hydrualic Bearing

Dimensions (DxWxH)
150 x 150 x 86 mm / 5.9 x 5.9 x 3.38 inches

PFC Type
Active PFC

Input Voltage Range
100-240V~

Power Watt
850W

Power Excursion
200%

Input Frequency Range
50-60Hz

Protection
OCP, OTP, OPP, SCP, OVP, UVP, SIP, NLO

ATX (24 pin)
1

EPS (4+4 pin)
2

PCI-E 5.1 (16 pin)
1 (600W)

PCI-E (6+2 pin)
3

SATA (15 pin)
6

Peripheral (4 pin)
2
