Gigabyte Z490 AORUS ELITE
Икона в кампания
НазадGigabyte Z490 AORUS ELITEGigabyte Z490 AORUS ELITEGigabyte Z490 AORUS ELITEGigabyte Z490 AORUS ELITEНапред

Дънна платка Gigabyte Z490 AORUS ELITE, Z490, LGA1200, PCI-E 3.0 (HDMI)(CF), 6x SATA3, 2x Ultra M.2, 2 x USB 3.2 Gen 2 Type-A, ATX

id 185334 Код: MBIGIGABYTEZ490AORUSELITE
  • Модел: Z490 AORUS ELITE
  • Марка: Gigabyte
  • Код на продукта: Z490 AORUS ELITE
  • Поддържана памет: DDR4
  • RAID: Да
  • Безжични мрежи: Не
  • Bluetooth: Не
  • Видео слот: PCI-E
  • Multi-Graphics технология: CrossFire
  • Гаранция: 36 месеца
  • Наличност: Стар продукт
    ОписаниеХарактеристикиРевюта / Въпроси





    !! Поддържа 10-та генерация Intel Core процесори !!







    Intel® Z490 AORUS Motherboard with Direct 12 Phase Digital VRM Design, Comprehensive Thermal Solution with Enlarged Surface Heatsink, 2.5GbE LAN, RGB FUSION 2.0

    • Supports 10th Gen Intel® Core™ Series Processors

    • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs

    • Intel® Optane™ Memory Ready

    • Direct 12 Phases Digital VRM Solution with 50A DrMOS

    • Shielded Memory Routing for Better Memory Overclocking

    • Advanced Thermal Design with Enlarged Surface Heatsink

    • AMP-UP Audio with ALC1200 and WIMA Audio Capacitors

    • Fast 2.5GbE LAN with Bandwidth Management

    • Dual Ultra-Fast NVMe PCIe 3.0 x4 M.2 with Thermal Guards

    • Pre-installed IO Shield for Easy and Quick Installation

    • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips

    • Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP

    • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card











    CPU
    Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1200 package
    L3 cache varies with CPU
    (Please refer "CPU Support List" for more information.)

    Chipset
    Intel® Z490 Express Chipset

    Memory
    4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    Dual channel memory architecture
    Support for DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
    * To support 3200 MHz, you must use XMP memory.
    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    Support for Extreme Memory Profile (XMP) memory modules

    Onboard Graphics
    Integrated Graphics Processor-Intel® HD Graphics support:
    1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
    * Support for HDMI 1.4 version and HDCP 2.3.
    Maximum shared memory of 512 MB

    Audio
    Realtek® ALC1200 codec
    High Definition Audio
    2/4/5.1/7.1-channel
    Support for S/PDIF Out

    LAN
    Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)

    Expansion Slots
    1 x PCI Express x16 slot, running at x16 (PCIEX16)
    * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    1 x PCI Express x16 slot, running at x4 (PCIEX4)
    2 x PCI Express x1 slots
    (All of the PCI Express slots conform to PCI Express 3.0 standard.)

    Multi-Graphics Technology
    Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

    Storage Interface
    2 x M.2 connectors (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2M_SB/M2A_SB)
    6 x SATA 6Gb/s connectors
    Support for RAID 0, RAID 1, RAID 5, and RAID 10
    * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
    Intel® Optane™ Memory Ready

    USB
    Chipset:
    2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    1 x USB Type-C™ port with USB 3.2 Gen 1 support, available through the internal USB header
    6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
    Chipset+2 USB 2.0 Hubs:
    8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

    Internal I/O Connectors
    1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    1 x 4-pin ATX 12V power connector
    2 x M.2 Socket 3 connectors
    6 x SATA 6Gb/s connectors
    1 x CPU fan header
    1 x water cooling CPU fan header
    3 x system fan headers
    2 x addressable LED strip headers
    2 x RGB LED strip headers
    1 x front panel header
    1 x front panel audio header
    1 x USB Type-C™ port, with USB 3.2 Gen 1 support
    1 x USB 3.2 Gen 1 header
    2 x USB 2.0/1.1 headers
    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    2 x Thunderbolt™ add-in card connectors
    1 x Clear CMOS jumper
    1 x Q-Flash Plus button

    Back Panel Connectors
    2 x USB 3.2 Gen 2 Type-A ports (red)
    4 x USB 3.2 Gen 1 ports
    4 x USB 2.0/1.1 ports
    1 x HDMI port
    1 x RJ-45 port
    1 x optical S/PDIF Out connector
    5 x audio jacks

    I/O Controller
    iTE® I/O Controller Chip
    H/W Monitoring
    Voltage detection
    Temperature detection
    Fan speed detection
    Water cooling flow rate detection
    Overheating warning
    Fan fail warning
    Fan speed control
    * Whether the fan speed control function is supported will depend on the fan you install.

    BIOS
    1 x 256 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features

    Unique Features
    Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    @BIOS
    EasyTune
    Fast Boot
    Game Boost
    ON/OFF Charge
    RGB Fusion
    Smart Backup
    System Information Viewer
    Support for Q-Flash Plus
    Support for Q-Flash
    Support for Xpress Install

    Bundled Software
    Norton® Internet Security (OEM version)
    Realtek® 8125 Gaming LAN Bandwidth Control Utility

    Operating System
    Support for Windows 10 64-bit

    Form Factor
    ATX Form Factor; 30.5cm x 24.4cm





    Виж още Дънни платки за Intel процесори Gigabyte
    Виж всички Дънни платки за Intel процесори в категорията
    Технически характеристики
    Процесор сокет:  LGA 1200
    Чипсет:  Z490
    Поддържана памет:  DDR4
    Брой слотове за RAM памет:  4
    Storage интерфейси:  SATA 6Gbit/s, M.2
    RAID:  Да
    Безжични мрежи:  Не
    Bluetooth:  Не
    Видео слот:  PCI-E
    Multi-Graphics технология:  CrossFire
    Видео изход:  HDMI
    Форм фактор:  ATX
