Gigabyte A620M S2H (rev. 1.0)
Икона в кампания
Gigabyte A620M S2H (rev. 1.0)Gigabyte A620M S2H (rev. 1.0)Gigabyte A620M S2H (rev. 1.0)Gigabyte A620M S2H (rev. 1.0)

Дънна платка Gigabyte A620M S2H, A620, AM5, DDR5, PCI-E 4.0 (VGA&DP&HDMI), 1x M.2, 4x SATA 6Gb/s, 2x USB 3.2 Gen 1, mATX

id 264658 Код: MBAGIGABYTEA620MS2H
  • Модел: A620M S2H (rev. 1.0)
  • Марка: Gigabyte
  • Код на продукта: A620M S2H (rev 1.0)
  • Поддържана памет: DDR5
  • RAID: Да
  • Безжични мрежи: Не
  • Bluetooth: Не
  • Видео слот: PCI-E
  • Multi-Graphics технология: Няма
  • Видеокарта: Вградена
  • Гаранция: 36 месеца
  • Наличност: Стар продукт
    ОписаниеХарактеристикиРевюта / Въпроси

    Gigabyte A620M S2H (rev 1.0)





    Tech specs:

    • CPU

      AMD Socket AM5, support for:
      AMD Ryzen 7000 Series Processors


    • Chipset

      AMD A620



    • Memory

      Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
      2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory
      Dual channel memory architecture
      Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules


    • Onboard Graphics

      Integrated Graphics Processor:
      - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
      - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz



      * Support for DisplayPort 1.4 version.
      - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz


      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support for native HDMI 2.1 TMDS compatible ports.


      (Graphics specifications may vary depending on CPU support.)
      Support for up to 3 displays at the same time



    • Audio

      Realtek Audio CODEC
      High Definition Audio
      2/4/5.1/7.1-channel



    • LAN

      Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)



    • Expansion Slots

      CPU:
      - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16


      Chipset:
      - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1



    • Storage Interface

      CPU:
      - 1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support)


      Chipset:
      - 4 x SATA 6Gb/s connectors
      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices



    • USB

      CPU:
      - 2 x USB 3.2 Gen 1 ports on the back panel
      - 1 x USB 2.0/1.1 port on the back panel


      Chipset:
      - 2 x USB 3.2 Gen 1 ports available through the internal USB header
      - 7 x USB 2.0/1.1 ports (3 ports on the back panel, 4 ports available through the internal USB headers)



    • Internal I/O Connectors

      1 x 24-pin ATX main power connector
      1 x 8-pin ATX 12V power connector
      1 x CPU fan header
      2 x system fan headers
      1 x addressable LED strip header
      1 x RGB LED strip header
      1 x M.2 Socket 3 connector
      4 x SATA 6Gb/s connectors
      1 x front panel header
      1 x front panel audio header
      1 x USB 3.2 Gen 1 header
      2 x USB 2.0/1.1 headers
      1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      1 x Clear CMOS jumper



    • Back Panel Connectors

      4 x USB 2.0/1.1 ports
      1 x PS/2 keyboard/mouse port
      1 x D-Sub port
      1 x Q-Flash Plus button
      2 x USB 3.2 Gen 1 ports
      1 x DisplayPort
      1 x HDMI port
      1 x RJ-45 port
      3 x audio jacks



    • I/O Controller

      iTE I/O Controller Chip



    • BIOS

      1 x 256 Mbit flash
      Use of licensed AMI UEFI BIOS
      PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0



    • Operating System

      Support for Windows 11 64-bit
      Support for Windows 10 64-bit



    • Form Factor

      Micro ATX Form Factor; 23.0cm x 22.5cm





    Виж още Дънни платки за AMD процесори Gigabyte
    Виж всички Дънни платки за AMD процесори в категорията
    Технически характеристики
    Процесор сокет:  AM5
    Чипсет:  A620
    Поддържана памет:  DDR5
    Брой слотове за RAM памет:  2
    Storage интерфейси:  SATA 6Gbit/s, M.2
    RAID:  Да
    Безжични мрежи:  Не
    Bluetooth:  Не
    Видео слот:  PCI-E
    Multi-Graphics технология:  Няма
    Видео изход:  DP HDMI VGA (D-Sub)
    Форм фактор:  Micro ATX
    Видеокарта:  Вградена
