FSP Hydro G PRO ATX 3.0

New ATX PSU Specifications

Updated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.

More Powerful with Compact Size

New HYDRO G Pro series upgrades from original HYDRO G, took the best features of HYDRO G series and made them even better. With smaller size, improves performance and more powerful output give you ultra-performance.

Complies with ATX12V V3.0 & EPS12V V2.92
Efficiency ≥ 90% at typical load
Intelligent fan speed control
Quiet and long-lasting 120mm FDB fan
Ribbon cables design for enthusiasts
Powerful +12V single rail design
105C Japanese electrolytic capacitors
Intel Latest CPU ready
Full protections: OCP, OVP, SCP, OPP, OTP
Conformal coatings for harsh environments

Specifications:

Model	HG2-850,Gen5
Rated Output Power	850W
Form Factor	ATX
80 PLUS Certification	Gold
Input Voltage	100-240Vac
Input Current	11-5.5A
Input Frequency	50-60Hz
PFC	Active PFC
Efficiency	90%
Fan Type	FDB Fan, 120mm
Dimensions(L x W x H)	150 x 150 x 86mm
Operation Temp.	0-50℃
Protection	OCP, OVP, OPP, SCP, OTP

AC Input	100-240Vac~ 11-5.5A 50-60Hz
DC Output	+3.3V	+5V	+12V	-12V	+5Vsb
Max Output Current	20A	20A	70.83A	0.3A	2.5A
Max Combined Power	120W		850W	3.6W	12.5W
Total Power	850W
