Name: Суич TP-Link Omada SG5428XMPP, 1000 Mbps, 28 порта, 24x 10/100/1000Mbps RJ-45 (8x PoE++, 16x PoE+), 4x SFP+, 1x USB-A
Brand: TP-Link
SKU: NTLHTPLINKSG5428XMPP
Price: 893.65 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси Вземи на изплащане

TP-Link Omada SG5428XMPP

Omada 24-Port Gigabit Stackable Lite L3 Managed PoE++ Switch with 4× 10G Slots

8× Gigabit 802.3af/at/bt PoE++ ports (Max 90W per port)
16× Gigabit 802.3af/at PoE+ ports (Max 30W per port)
4× 10 Gbps SFP+ slots
Up to 500W total PoE budget*
Fast PoE and Perpetual PoE
Physical stacking up to 4 units for built-in redundancy and performance
L3 features: RIP, OSPF, Static Routing, and DHCP Server/Relay
Security strategies: ACL, Port Security, DoS Defend, 802.1X
ERPS supports rapid protection and recovery in a ring topology
Centralized cloud management via the Omada SDN controller
Standalone management via web, CLI, SNMP, and RMON

Omada SG5428XMPP is a dependable entry-level L3 managed PoE++ switch tailored for the access layer, featuring L3 routing, fast 10 Gbps wired speeds, and stacking options. It boasts a 500W PoE budget,* 24× gigabit RJ45 ports (8× PoE++, 16× PoE+), 4× 10 Gbps SFP+ slots, physical stacking ability, and centralized management. Integrated with strong security and extensive management features, the SG5428XMPP offers a reliable networking solution for SMEs, and ISPs.

Параметър	Спецификация
Интерфейс	• 24× 10/100/1000 Mbps RJ45 Ports (8× PoE++, 16× PoE+) • 4× 1/10 Gbps SFP+ Slots • 1× USB 2.0 Port • 1× RJ45 Console Port • 1× USB Type-C Console Port
Брой вентилатори	3
Захранване	100-240 V~ 50/60 Hz
PoE портове (RJ45)	• Standard: 802.3af/at/bt compliant • PoE++ Ports: Ports 1~8 (up to 90W per Port) • PoE+ Ports: Ports 9~24 (up to 30W per Port) • Power Budget: 500W • Fast PoE • Perpetual PoE
Размери (Ш x Д x В)	17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)
Монтаж	Rackmountable
Макс. консумация на енергия	• 587.7 W (220V/50Hz) (with 500 W PD connected @ 25 °C) • 615.8 W (110V/60Hz) (with 500 W PD connected @ 25 °C)
Max. Heat Dissipation	• 2004.06 BTU/hr (220V/50Hz) (with 500 W PD connected @ 25 °C) • 2099.88 BTU/hr (110V/60Hz) (with 500 W PD connected @ 25 °C)
Комутационен капацитет	128 Gbps per Unit
Stacking	• Stacking Number: 4 • Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports) • Stacking Bandwidth: Up to 80 Gbps (4 stacking ports)
Скорост на предаване на пакети данни	95.23 Mpps
Таблица на МАС адресите	16 K
Packet Buffer Memory	12 Mbit
Jumbo кадър	9 KB
Качество на услугата	• Class of Service - 8 Queues of Priority • Port Priority • IEEE 802.1p Priority • DSCP Priority • Queue Min-Bandwidth • Schedule Mode (SP, WRR, SP+WRR) • Bandwidth Control • Rate Limit • Storm Control • Voice VLAN • User-Defined OUI • Smoother Performance • Action for Flows • QoS remark (802.1P Remark, DSCP Remark)
L3 Features	• IP Interfaces: IPv4 Max 128, IPv6 Max 128 • Static Routing: IPv4 Max 512, IPv6 Max 128 • Host Route Table: Max 1,024 entries • RIP: Version v1/v2, Max 1,796 • OSPF: Version v2/v3; v2 Max 1,796, v3 Max 450 • Static ARP: 512 static entries • Dynamic ARP: 3,600 dynamic entries • Proxy ARP • DHCP Server: Max 64 IP Pools, Max 1,000 Manual Binding Entries • DHCP Relay: Relayed Interface, Relayed VLAN
L2 and L2+ Features	• Link Aggregation • Spanning Tree Protocol • Port-based and VLAN-based Loopback Detection • 802.3x Flow Control • ERPS • Mirroring • RSPAN • MAC Address Table • Multicast: IGMP Snooping, MLD Snooping, L2 Multicast Table Max 2,000, Fast Leave, Multicast VLAN Registration (MVR), Static Multicast Groups, Multicast Filtering
Разширени характеристики	• Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • ISP Features: 802.3ah Ethernet Link OAM, L2PT (Layer 2 Protocol Tunneling), Device Link Detect Protocol (DLDP), DDM, sFlow
VLAN	• Max 4K VLAN Group (802.1q VLAN) • 802.1Q Tagged VLAN • MAC VLAN Entries: 60 • Multicast VLAN • Management VLAN • VLAN VPN (QinQ): Max 256 entries • GVRP • Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries • Voice VLAN • Private VLAN
Защита	• Port Isolation • CPU-Defend • ARP Inspection (Dynamic ARP Inspection) • DoS Defend • IP-MAC-Port Binding: 1,024 Entries • DHCP Snooping • ARP Inspection • IPv4 Source Guard • IPv6-MAC-Port Binding: 1,024 Entries • DHCPv6 Snooping • ND Detection • ND Snooping • IPv6 Source Guard • DHCP Filter • Static/Dynamic Port Security: Up to 64 MAC addresses per port • Broadcast/Multicast/Unknown-unicast Storm Control • 802.1X: Port base authentication, Mac base authentication, VLAN Assignment, MAB, Guest VLAN, RADIUS authentication and accountability support • AAA (including TACACS+) • Secure web management through HTTPS with SSLv3/TLS 1.2 • Secure CLI management with SSHv2 • IP/Port/MAC-based access control
Omada App	Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller
Cloud Access	Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning	Yes. Requiring the use of the Omada Cloud-Based Controller.
Management Features	• Web-based GUI • Command Line Interface (CLI) through console port, telnet • SNMPv1/v2c/v3 • Trap/Inform • RMON (1, 2, 3, 9 groups) • SDM Template • DHCP/BOOTP Client • 802.1ab LLDP/LLDP-MED • DHCP Auto Install • Dual Image, Dual Configuration • CPU Monitoring • Cable Diagnostics • Password Recovery • SNTP • System Log • IEEE 802.3az Energy Efficient Ethernet (EEE)
