FSP FFSP180-50FEB

FSP180-50FEB is a standard Flex form factor switching power supply. The power supply comes to offer the total power capacity up to 180 Watts, which makes it to be ideally used in an industrial environment. In addition, the power supply is ideally the best choice for IPC controller, networking, communication or any other automation applications to use. The product also complies with the latest safety and EMC standards, which is perfectly to meet various regulations worldwide.

Certified CB 62368-1 & CB 60950-1
Meet 80 Plus Bronze
Design for 5,000 Meters above sea level
High Reliability
Low Ripple & Noise
Over Current Protection
Over Temperature Protection
Over Voltage Protection

Specifications:

		Working temperature:	0°C to 50°C
		Storage temperature:	-20°C to + 80°C
Efficiency:	80 Plus Bronze	Working humidity:	85%	RH non-condensing
		Storage humidity:	95%	RH non-condensing
Hold-up time at 100%	115V / 60Hz: ≥ 16ms
Loading:	230V / 50Hz: ≥ 16ms	MTBF:	100,000 hours of continuous operation at 25°C, Max,-output load
Operating altitude:	5,000 meters above sea level	Applications:	Networking ,Storage System ,IPC Controller

Outputs	+3.3V		+5V	+12V	-12V	+5Vsb
Max.	8.0A	12.0A		12.0A	0.3A	2.0A
Min.	0.0A	0.0A		0.05A	0.0A	0.0A
Regulation	±5%	±5%		±5%	±10%	±5%
Ripple/Noise	50 mV	50 mV		120 mV	120 mV	50 mV
