Name: Дънна платка Biostar A520MH 3.0, A520, AM4, DDR4, PCIe 3.0 (HDMI&VGA), 4x SATA 6Gb/s, 1x M.2, 4x USB 3.2, 2x USB 2.0
Brand: Biostar
SKU: MBABIOSTARBIOMBA520MH3
Availability: OutOfStock

Описание Характеристики Ревюта / Въпроси

Дънна платка Biostar A520MH 3.0, A520, AM4, DDR4, PCIe 3.0 (HDMI&VGA), 4x SATA 6Gb/s, 1x M.2, 4x USB 3.2, 2x USB 2.0 - характеристика 1

Дънна платка Biostar A520MH 3.0, A520, AM4, DDR4, PCIe 3.0 (HDMI&VGA), 4x SATA 6Gb/s, 1x M.2, 4x USB 3.2, 2x USB 2.0 - характеристика 2

Дънна платка Biostar A520MH 3.0, A520, AM4, DDR4, PCIe 3.0 (HDMI&VGA), 4x SATA 6Gb/s, 1x M.2, 4x USB 3.2, 2x USB 2.0 - характеристика 3

Дънна платка Biostar A520MH 3.0, A520, AM4, DDR4, PCIe 3.0 (HDMI&VGA), 4x SATA 6Gb/s, 1x M.2, 4x USB 3.2, 2x USB 2.0 - характеристика 4

Дънна платка Biostar A520MH 3.0, A520, AM4, DDR4, PCIe 3.0 (HDMI&VGA), 4x SATA 6Gb/s, 1x M.2, 4x USB 3.2, 2x USB 2.0 - характеристика 5

Specifications

Chipset	AMD A520
CPU SUPPORT	Socket AM4 support AMD 3rd Gen Ryzen™ (Matisse/ Renoir) processors and Ryzen™ 4th Gen (Vermeer) processors Support for future AMD Ryzen processors with BIOS update * Please refer to www.biostar.com.tw for CPU support list.
MEMORY	3rd Gen AMD Ryzen Processors (Matisse CPUs) Supports for DDR4 4400+(OC) / 4000(OC) / 3800(OC) / 3600(OC) / 3200/ 2933 / 2667 / 2400 / 2133 / 1866 3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs) Supports for DDR4 4933+(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4000(OC) / 3800(OC) / 3600(OC) / 3200 / 2933 / 2667 / 2400 / 2133 / 1866 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory Each DIMM supports non-ECC 8/ 16/ 32 GB DDR4 module * Please refer to www.biostar.com.tw for Memory support list.
INTEGRATED VIDEO	By CPU model Supports DX12 Supports HDCP
STORAGE	4 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10 1 x M.2 (M Key) Socket: Supports M.2 Type 2242/ 2260/ 2280 SSD module Supports PCIe 3.0 x 4 (32Gb/s) Supports SATA III (6.0Gb/s) SSD
LAN	Realtek RTL8111H 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability Supports Super LAN Surge Protection
AUDIO CODEC	ALC887 7.1 Channels, High Definition Audio, Hi-Fi (Front)
USB	6 x USB 3.2 (Gen1) ports (4 on rear I/Os and 2 via internal headers) 6 x USB 2.0 ports (2 on rear I/Os and 4 via internal headers)
EXPANSION SLOT	1 x PCIe 3.0 x 16 Slot: Supports PCIe 3.0 x 16 mode with AMD Ryzen™ processors. (Matisse only) Supports PCIe 3.0 x 16 mode AMD Ryzen™ with Radeon Vega Graphics processors. (Renoir only) 2 x PCIe 3.0 x 1 Slots * According to different CPUs will have different speeds.
REAR I/O	1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x HDMI Port 1 x VGA Port 1 x LAN port 4 x USB 3.2 (Gen1) Ports 2 x USB 2.0 Ports 3 x Audio Jack
INTERNAL I/O	4 x SATA III (6.0Gb/s) Connectors 2 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Clear CMOS Header 1 x Internal Stereo Speaker Header 1 x COM Port Header
H/W MONITORING	CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring
DIMENSION	Micro ATX Form Factor Dimension: 24.4cm x 20.8cm ( W x L )

Виж още Дънни платки за AMD процесори Biostar
Виж всички Дънни платки за AMD процесори в категорията

Технически характеристики

Процесор сокет:	AM4
Чипсет:	A520
Поддържана памет:	DDR4
Брой слотове за RAM памет:	2
Storage интерфейси:	SATA 6Gbit/s, M.2
RAID:	Не
Безжични мрежи:	Не
Bluetooth:	Не
Видео слот:	PCI-E
Multi-Graphics технология:	Няма
Видео изход:	HDMI VGA (D-Sub)
Форм фактор:	Micro ATX
Видеокарта:	Няма
