Дънна платка Asus Prime A320M-A, A320, AM4, DDR4, PCI-E(HDMI,DVI,VGA), 4x SATA 6Gb/s, 1x M.2 слот, 2x USB 3.1 Gen 1, mATX

AMD AM4 uATX motherboard with LED lighting, DDR4 3200 MHz, 32Gb/s M.2, SATA 6Gb/s, HDMI,USB 3.0

• 5X Protection III: Multiple hardware safeguards for all-round protection
• LED illumination: Lighting control for audio trace paths
• Native M.2: Lightning-fast storage speeds
• One-stop controls: Media-acclaimed UEFI BIOS with EZ Flash 3

Tech Specs

CPU:
- AMD AM4 Socket for AMD Ryzen™/7th Generation A-series/Athlon™ Processors
Supports CPU up to 8 cores

Chipset:
- AMD A320

Memory:
- AMD Ryzen™ Processors
4 x DIMM, Max. 64GB, DDR4 3200(O.C.)/2933(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory *1
- AMD 7th Generation A-series/Athlon™ Processors
4 x DIMM, Max. 64GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory
- Dual Channel Memory Architecture

Graphic:
- Integrated AMD Radeon™ R Series Graphics in the 7th Generation A-Series APU *2
- Multi-VGA output support : HDMI/DVI/RGB ports
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
- Maximum shared memory of 2048 MB

Expansion Slots:
- AMD Ryzen™ Processors
1 x PCIe 3.0/2.0 x16 (x16 mode)
- AMD 7th Generation A-series/Athlon™ Processors
1 x PCIe 3.0/2.0 x16 (x8 mode)
- AMD A320 chipset
2 x PCIe 2.0 x1

Storage:
- AMD A320 chipset :
4 x SATA 6Gb/s port(s), gray,
- Support Raid 0, 1, 10
- AMD Ryzen™/7th Generation A-series/Athlon™ Processors :
2 x SATA 6Gb/s port(s), gray,
- AMD Ryzen™ Processors :
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*3
- AMD 7th Generation A-series/Athlon™ Processors :
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)*4

LAN:
- Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)

Audio:
- Realtek® ALC887 8-Channel High Definition Audio CODEC

USB Ports:
- AMD Ryzen™/7th Generation A-series/Athlon™ Processors :
4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
- AMD A320 chipset :
2 x USB 3.1 Gen 1 port(s) (2 at mid-board)
- AMD A320 chipset :
6 x USB 2.0 port(s)

Special Features:
ASUS 5X Protection III :
- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
- ASUS Overvoltage Protection: World-class circuit-protecting power design
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- ASUS DIGI+ VRM: 6 Phase digital power design
ASUS Exclusive Features :
- AI Suite 3
- Ai Charger
- Turbo LAN
- PC Cleaner
ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-sink solution
- ASUS Fan Xpert
ASUS EZ DIY :
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- Multi-language BIOS
ASUS Q-Design :
- ASUS Q-Slot
- ASUS Q-DIMM

Operating System Support:
- Windows® 10 , 64bit

Back I/O Ports:
- 1 x PS/2 keyboard (purple)
- 1 x PS/2 mouse (green)
- 1 x DVI-D
- 1 x D-Sub
- 1 x HDMI
- 1 x LAN (RJ45) port(s)
- 4 x USB 3.1 Gen 1 (blue)
- 2 x USB 2.0
- 3 x Audio jack(s)

Internal I/O Ports:
- 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
- 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode)
- 1 x COM port(s) connector(s)
- 6 x SATA 6Gb/s connector(s)
- 1 x CPU Fan connector(s) (1 x 4 -pin)
- 1 x Chassis Fan connector(s) (1 x 4 -pin)
- 1 x S/PDIF out header(s)
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin ATX 12V Power connector(s)
- 1 x Front panel audio connector(s) (AAFP)
- 1 x System panel(s)
- 1 x Clear CMOS jumper(s)
- 1 x Speaker connector

Accessories:
- User's manual
- I/O Shield
- 2 x SATA 6Gb/s cable(s)
- 1 x M.2 Screw Package
- 1 x Supporting DVD

BIOS:
128 Mb Flash ROM, UEFI AMI BIOS, PnP,WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control

Operating System:
- Windows® 10 64-bit

Form Factor:
- Micro ATX Form Factor
9.6 inch x 9.45 inch ( 24.4 cm x 24 cm
