Name: Монитор IIYAMA TF1515MC-B2, 15 (38.10 cm) TN панел, XGA, 8ms, 350cd/m2, DP/HDMI/VGA
Brand: Iiyama
SKU: MNLCIIYAMATF1515MCB2
Price: 495.67 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси Документация Вземи на изплащане

IIYAMA TF1515MC-B2

Design	Open Frame
Diagonal	15", 38cm
Panel	TN LED
Native resolution	1024 x 768 (0.8 megapixel)
Aspect ratio	4:3
Brightness	350 cd/m² typical
Brightness	315 cd/m² with touch
Static contrast	800:1 with touch
Light transmittance	90%
Response time (BTB)	8ms
Viewing zone	horizontal/vertical: 160°/150°, right/left: 80°/80°, up/down: 75°/75°
Colour support	16.2mln (6bit + Hi-FRC)
Horizontal Sync	31.4 - 60kHz
Viewable area W x H	304.1 x 228.1mm, 12 x 9"
Pixel pitch	0.297mm
Bezel colour and finish	black

Touch technology	projective capacitive
Touch points	10 (HID, only with supported OS)
Touch method	stylus, finger, glove (latex)
Touch interface	USB
Supported operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Through-Glass	6mm

Analog signal input	VGA x1
Digital signal input	HDMI x1 DisplayPort x1
Audio output	Mini jack x1
HDCP	yes

Extra	anti-fingerprint coating, touch through-glass, foam seal
60950 Ball drop test	yes
Water and dust protection	IP65 (front)
OSD key lock	yes

OSD languages	EN, DE, FR, ES, IT, CN, JP
Control buttons	menu,scroll up/ brightness, scroll down/ contrast, select, power
User controls	picture (contrast, brightness, H.position, V.position, H.size, phase, clock, auto adjust), advanced (colour temperature, sharpness), OSD (OSD timeout, OSD position, OSD H.position, OSD V.position, touch switch), option (reset, language, source select, display mode, factory)
Plug&Play	DDC2B

MECHANICAL

Orientation	landscape, portrait, face-up
VESA mounting	100 x 100mm
Operation temperature range	0°C - 40°C
Storage temperature range	- 20°C - 60°C

Виж още Монитори Iiyama
Виж всички Монитори в категорията

Документация

Технически характеристики

Портове
HDMI:	Да
DisplayPort:	Да
VGA (D-Sub):	Да

Гама:	Home & Office
Екран размер:	15" (38.10 cm)
Разделителна способност (max):	1024 x 768
Тип матрица:	TN
Аспект изображение:	4:3
Честота на опресняване:	60 Hz
Време за реакция:	8 ms
Яркост:	350 cd/m²
TV Тунер:	Не
Тъчскрийн:	Да
Вградени колони:	Не
3D:	Не
Цвят:	Черен
Формат екран:	Classic
Извит:	Не
Преносим:	Не
