Planet VC-201A, от Ethernet към VDSL2 media converter, до 1.6км

Planet VC-201A

High Performance Ethernet over VDSL Solution
PLANET VC-201A is an Ethernet-over-VDSL2 media converter with high performance. It is designed based on two core networking technology, Ethernet and VDSL2 (Very-high-data-rate Digital Subscriber Line 2). The VDSL2 technology offers the absolutely fastest data transmission speeds over existing copper telephone lines without the need of rewiring. The VC-201A supports ultra-high performance to the pervasive telephone line network with up to 100/55Mbps asymmetric data rate within 200m and 25/4Mbps for 1.6km long range connections.

Cost-effective VDSL2 CO / CPE bridge solution
• One box design, CO / CPE selectable via DIP Switch
• Defines asymmetric (Plan 998) and symmetric (Plan 997) band plans for the
　transmission of upstream and downstream signals
• Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards
• DMT (Discrete Multi-Tone) line coding
• Half duplex Back pressure and IEEE 802.3x Full Duplex Pause frame flow control
• Built-in POTS splitter to share voice and data
• Two RJ-11 connectors for each VDSL port, one for VDSL connection and one for POTS
　connection
• Voice and data communication can be shared simultaneously based on the existing
　telephone wire
• Supports up to 1536 bytes packet size, IEEE 802.1Q VLAN tag transparent
• VDSL2 stand-alone transceiver for simple bridge modem application
• Advantage of minimum installation time (Simply as Plug-and-Play)
• Selectable target band plan and target SNR margin
• Supports extensive LED indicators for network diagnostics
• Co-work with PLANET MC family Media Chassis (MC-700 / MC-1500/ MC-1500R / MC-1500R48)
• Compact in size, easy installation

Hardware Specifications
Ports 10/100Base-TX: 1 RJ-45, Auto-negotiation and Auto-MDI / MDI-X
VDSL: 1 RJ-11, female Phone Jack
PHONE: 1 RJ-11, Built-in splitters for POTS connection
DIP Switch 4 position DIP switch
Functionality • CO / CPE mode select
• Selectable fast and interleaved mode
• Selectable target band plan
• Selectable target SNR mode
Encoding • VDSL-DMT
　- ITU-T G.993.1 VDSL
　- ITU-T G.997.1
　- ITU-T G.993.2 VDSL2 (Profile 17a Support)
LED Indicators • One Power
• 3 for RJ-11 / VDSL2 WAN :
　- Green, LNK / ACT
　- Green, CO mode
　- Green, CPE mode
• 2 for per RJ-45 10/100Base-TX port
　- Green, LNK / ACT
　- Green, Speed
Cabling Type • 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
• 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)
• VDSL: twisted-pair telephone wires (AWG24 or better) up to 1.6km
Performance Full VDSL2 bandwidth up to: (Down Stream / Up Stream)

• Asymmetric Mode
　- 200m -> 100/55Mbps
　- 400m -> 90/50Mbps
　- 600m -> 70/40Mbps
　- 800m -> 60/25Mbps
　- 1000m -> 45/15Mbps
　- 1200m -> 35/10Mbps
　- 1400m -> 30/6Mbps
　- 1600m -> 25/4Mbps

• Symmetric Mode
　- 200m -> 90/90Mbps
　- 400m -> 90/90Mbps
　- 600m -> 70/70Mbps
　- 800m -> 55/50Mbps
　- 1000m -> 40/35Mbps
　- 1200m -> 30/25Mbps
　- 1400m -> 25/20Mbps
　- 1600m -> 20/15Mbps

Dimensions (W x D x H) 97 x 69 x 26 mm
Weight 0.4 kg
Power Requirement 5V DC 2A
Operating Temperature 0~50 degrees C
Storage Temperature -25~70 degrees C
Operating Humidity 10~90%, relative humidity, non-condensing
Storage Humidity 10~90%, relative humidity, non-condensing
Standard Conformance
Regulation Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
ITU-T
　- G.993.1 (VDSL)
　- G.997.1
　- G.993.2 VDSL2 (Profile 17a )
