Дънна платка за сървър Intel S1200SPSR, LGA 1151, поддържа ECC UDIMM DDR4 RAM, 2x Lan1000, 6x SATA 6.0Gb/s RAID 0/1/10/5, 2x USB 3.0, Display Port, VGA, uATX

Intel® Server Board S1200SPSR


Compatible Product Series: Intel® Xeon® Processor E3-1200 v5 Family
Board Form Factor: uATX
Chassis Form Factor: Pedestal
Socket: 1
Integrated BMC with IPMI: IPMI 2.0
TDP: 80 W
Board Chipset: Intel® C232 Chipset
Target Market: Small and Medium Business

Memory Specifications

Max Memory Size (dependent on memory type): 64 GB
Memory Types: DDR4 ECC UDIMM
Max # of Memory Channels: 2
Max Memory Bandwidth: 68.256 GB/s
Physical Address Extensions: 40-bit
Max # of DIMMs: 4
ECC Memory Supported: Yes
DIMM Type: UDIMM

Graphics Specifications

Graphics Output: VGA

Expansion Options

PCI Express Revision: 3.0
Max # of PCI Express Lanes: 20
PCIe x4 Gen 3: 1
PCIe x8 Gen 3: 2

I/O Specifications

USB Revision 2.0 & 3.0
# of USB Ports 7
Total # of SATA Ports: 6
RAID Configuration: Software RAID RST (0,1,10,5) and ESRT2 (0,1,10)
# of Serial Ports: 1
# of LAN Ports: 2
Integrated LAN: 2x 1GbE

Package Specifications

Max CPU Configuration 1
Low Halogen Options Available See MDDS

Advanced Technologies

Intel® Virtualization Technology for Directed I/O (VT-d): Yes
Intel® Node Manager: Yes
Intel® Rapid Storage Technology enterprise: Yes
Intel® I/O Acceleration Technology: Yes
Security & Reliability:
Intel® Trusted Execution Technology: Yes
