DICOM Medical Grade Touchscreen Monitors

The 03-Series Medical Grade Touchscreen Monitors merge best-in-class touchscreen technology with DICOM Part 14 functionality to help enhance clinical review for healthcare providers while increasing patient engagement. With a compact form factor and sleek design, the touchscreen monitors are well-suited for EMR documentation, image viewing, clinical collaboration, deployment within the laboratory and pharmacy and for integration into medical devices.

DICOM 14 -Designed for Consistent Image Review

Get the image accuracy you need during clinical review with the 03-Series medical grade touch screen monitors. To help ensure healthcare providers and patients can view clear, accurate and consistent medical images, the displays are pre-calibrated from the factory per AAPM secondary display guidelines in compliance with the DICOM 14 GSDF curve.

Размер:	23.8"
Резолюция:	1920x1080
Формат:	16:9
Подсветка:	LED
Тъчскрийн технология:	Capacitive multi touch
Тъчскрийн интерфейс:	USB & Serial
Покритие на екрана:	Anti-Glare
Яркост:	250 cd/m2
Статичен контраст:	1000 :1
Ъгли на виждане:	178º / 178º
Време за реакция:	16 ms
Цветове на дисплея:	16.7 M
Колонки:	2 x 2W
VGA:	1 x VGA
HDMI:	1 x HDMI
USB-HUB:	1 x USB 3.0
Аудио:	1 x 3.5 mm Combo Jack
Изходи:	4 x Micro USB side ports (Top, Bottom, Left, Right)
VESA:	100x100
Функции:	DICOM Part 14 (AAPM secondary display) ; Impact Protection IK06 ; RS232 touch supported via E810917
Включени аксесоари:	Touchmonitor, Quick Install Guide, 3x Tie wraps, VGA cable, HDMI cable, Touch USB cable, Audio cable, Power brick (E323104), NA Power cable, EU Power cable, EEI Label, DICOM calibration sheet
Енергопотребление:	15.68 W
Сертификати:	UL: AAMI /ANSI ES60601-1:2005/(R)2012 and A1:2012, C1:2009/(R)2012 and A2:2010/(R)2012/IEC 60601-1 Ed. 3.1, cUL: (CAN/CSA-C22.2 NO. 60601-1:14 /IEC60601-1 Ed. 3.1, CB: IEC 60601-1:2005+A1:2012 (Ed. 3.1), CE: IEC 60601-1-2:2014 (Ed. 4), Risk Management: IS
Цвят на корпуса:	Черен
Индекс на индустриална защита:	IP54
