DICOM Medical Grade Touchscreen Monitors
The 03-Series Medical Grade Touchscreen Monitors merge best-in-class touchscreen technology with DICOM Part 14 functionality to help enhance clinical review for healthcare providers while increasing patient engagement. With a compact form factor and sleek design, the touchscreen monitors are well-suited for EMR documentation, image viewing, clinical collaboration, deployment within the laboratory and pharmacy and for integration into medical devices.
DICOM 14 -Designed for Consistent Image Review
Get the image accuracy you need during clinical review with the 03-Series medical grade touch screen monitors. To help ensure healthcare providers and patients can view clear, accurate and consistent medical images, the displays are pre-calibrated from the factory per AAPM secondary display guidelines in compliance with the DICOM 14 GSDF curve.
| Размер: | 21.5" |
| Резолюция: | 1920x1080 |
| Формат: | 16:9 |
| Подсветка: | LED |
| Тъчскрийн технология: | Capacitive multi touch |
| Тъчскрийн интерфейс: | USB & Serial |
| Покритие на екрана: | Anti-Glare |
| Яркост: | 250 cd/m2 |
| Статичен контраст: | 1000 :1 |
| Ъгли на виждане: | 178º / 178º |
| Време за реакция: | 14 ms |
| Цветове на дисплея: | 16.7 M |
| Колонки: | 2 x 2W |
| HDMI: | 1 x HDMI |
| USB-HUB: | 1 x USB 3.0 |
| Аудио: | 1 x 3.5 mm Combo Jack |
| Изходи: | 4 x Micro USB side ports (Top, Bottom, Left, Right) |
| VESA: | 100x100 |
| Функции: | DICOM Part 14 (AAPM secondary display) ; Impact Protection IK06 ; RS232 touch supported via E810917 |
| Включени аксесоари: | Touchmonitor, Quick Install Guide, 3x Tie wraps, VGA cable, HDMI cable, Touch USB cable, Audio cable, Power brick (E323104), NA Power cable, EU Power cable, EEI Label, DICOM calibration sheet |
| Енергопотребление: | 14.4 W |
| Сертификати: | UL: AAMI /ANSI ES60601-1:2005/(R)2012 and A1:2012, C1:2009/(R)2012 and A2:2010/(R)2012/IEC 60601-1 Ed. 3.1, cUL: (CAN/CSA-C22.2 NO. 60601-1:14 /IEC60601-1 Ed. 3.1, CB: IEC 60601-1:2005+A1:2012 (Ed. 3.1), CE: IEC 60601-1-2:2014 (Ed. 4), Risk Management: IS |
| Цвят на корпуса: | Бял |
| Индекс на индустриална защита: | IP54 |
Виж още Специализирани Монитори Elo
Виж всички Специализирани Монитори в категорията
| Екран размер: | 21.5" (54.61 cm) |
|---|---|
| Тип: | Медицински дисплей |
| Енергиен клас: | E |
