Медицински тъч монитор Elo 1903LM (E658394), 19" (48.26 cm) SXGA LED панел, HDMI, VGA, USB

DICOM Medical Grade Touchscreen Monitors

The 03-Series Medical Grade Touchscreen Monitors merge best-in-class touchscreen technology with DICOM Part 14 functionality to help enhance clinical review for healthcare providers while increasing patient engagement. With a compact form factor and sleek design, the touchscreen monitors are well-suited for EMR documentation, image viewing, clinical collaboration, deployment within the laboratory and pharmacy and for integration into medical devices.



DICOM 14 -Designed for Consistent Image Review

Get the image accuracy you need during clinical review with the 03-Series medical grade touch screen monitors. To help ensure healthcare providers and patients can view clear, accurate and consistent medical images, the displays are pre-calibrated from the factory per AAPM secondary display guidelines in compliance with the DICOM 14 GSDF curve.



Размер:	19"
Резолюция:	1280x1024
Формат:	5:4
Подсветка:	LED
Тъчскрийн технология:	Capacitive multi touch
Тъчскрийн интерфейс:	USB & Serial
Покритие на екрана:	Anti-Glare
Яркост:	250 cd/m2
Статичен контраст:	1000 :1
Ъгли на виждане:	178º / 178º
Време за реакция:	14 ms
Цветове на дисплея:	16.7 M
Колонки:	2 x 2W
VGA:	1 x VGA
HDMI:	1 x HDMI
USB-HUB:	1 x USB 2.0
Аудио:	1 x Combo Jack
Изходи:	4 x Micro USB side ports (Top, Bottom, Left, Right), 1 x USB Type B
VESA:	100x100
Функции:	DICOM Part 14 (AAPM secondary display) ; Impact Protection IK06 ; RS232 touch supported via E810917
Включени аксесоари:	Touchmonitor with stand, Quick Install Guide, 3x Tie wraps, VGA cable, HDMI cable, Touch USB cable, Audio cable, Power brick (E323104), NA Power cable, EU Power cable, EEI Label, DICOM calibration sheet
Енергопотребление:	16.36 W
Сертификати:	UL: AAMI /ANSI ES60601-1:2005/(R)2012 and A1:2012, C1:2009/(R)2012 and A2:2010/(R)2012/IEC 60601-1 Ed. 3.1 ; cUL: (CAN/CSA-C22.2 NO. 60601-1:14 /IEC60601-1 Ed. 3.1; CB: IEC 60601-1:2005+A1:2012 (Ed. 3.1); CE: IEC 60601-1-2:2014 (Ed. 4); Risk Management: I
Цвят на корпуса:	Черен
Индекс на индустриална защита:	IP54
