Дънна платка Gigabyte Z790 AORUS MASTER X (rev 1.0), Z790, LGA1700, DDR5, PCIe 5.0 (DP), 5x M.2, 4x SATA 6Gb/s, 2x USB 3.2 Gen 2x2, 7x USB 3.2 Gen 2 Type-A, Wi-Fi 7, 10GbE LAN, E-ATX

Gigabyte Z790 AORUS MASTER X

• Supports Intel Core 14th and 13th processors
• Digital direct 20+1+2 phases VRM solution
• Dual Channel DDR5：4*DIMMs with XMP 3.0 memory module support
• PCIe UD Slot X： PCIe 5.0 x16 slot with 10X strength for graphics card
• EZ-Latch Click：M.2 heatsinks with screwless design
• EZ-Latch Plus：PCIe 5.0 x16 slot & M.2 slots with quick release design
• UC BIOS：User-Centred intuitive UX with Quick Access function
• Ultra-Fast Storage：5*M.2 slots, including 1* PCIe 5.0 x4
• Efficient Overall Thermal：VRM Thermal Armor Fins-Array & M.2 Thermal Guard XL
• Fast Networking：10GbE LAN & Wi-Fi 7 with Ultra-high gain antenna
• Extended Connectivity：DP, Front USB-C 10Gb/s, Front & Dual Rear USB-C 20Gb/s
• DTS:X® Ultra Audio：ALC1220 & Rear ESS SABRE Hi-Fi 9118 DAC

X Gen Designed for 14th Gen

X marks the 14th generation! Introducing the AORUS Z790 X Gen Motherboards, the most powerful platforms ever built for the Intel Core 14th Gen processors. With the leading performance in DDR5 memory, the upgraded DIY-friendly innovations, and the all-new BIOS redesigned as user-centered, the AORUS Z790 X Gen Motherboards are built to fully unleash the next-gen power.

Tech specs:

   CPU
   LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors
   L3 cache varies with CPU


   Chipset
   Intel Z790 Express Chipset

   Memory
       Support for DDR5 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
       4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture
       Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
       Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
       Support for Extreme Memory Profile (XMP) memory modules


   Onboard Graphics
   Integrated Graphics Processor-Intel® HD Graphics support:
   - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

   * Support for DisplayPort 1.2 version and HDCP 2.3

   Audio
   Realtek ALC1220-VB CODEC

   * The front panel line out jack supports DSD audio.

   ESS ES9118 DAC chip
   Support for DTS:X Ultra
   High Definition Audio
   2/4/5.1-channel

   Support for S/PDIF Out

   LAN
   Marvell AQtion AQC113C 10GbE LAN chip
   (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)

   Wireless Communication module
   Qualcomm Wi-Fi 7 QCNCM865 (PCB rev. 1.0)
   - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
   - BLUETOOTH 5.3
   - Support for 11be 320MHz wireless standard

   Expansion Slots
   CPU:
   - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)

   * The PCIEX16 slot shares bandwidth with the M2C_CPU connector. The PCIEX16 slot operates at up to x8 mode when a device is installed in the M2C_CPU connector.
   * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

   Chipset:
   - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
   - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)

   Storage Interface
   CPU:
   - 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0 x4/x2 SSD support) (M2C_CPU)
   - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)

   Chipset:
   - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
   - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2P_SB)
   - 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
   - 4 x SATA 6Gb/s connectors
   RAID 0, RAID 1, RAID5, and RAID 10 support for NVMe SSD storage devices
   RAID 0, RAID 1, RAID5, and RAID 10 support for SATA storage devices

   USB
   Chipset:
   - 3 x USB Type-C ports, with USB 3.2 Gen 2x2 support (2 ports on the back panel, 1 port available through the internal USB header)

   Chipset+2 USB 3.2 Gen 2 Hubs:
   - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support
   - 7 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

   Chipset+2 USB 3.2 Gen 1 Hubs:
   - 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

   Chipset+USB 2.0 Hub:
   - 4 x USB 2.0/1.1 ports available through the internal USB headers

   Internal I/O Connectors
   1 x 24-pin ATX main power connector
   2 x 8-pin ATX 12V power connectors
   1 x CPU fan header
   1 x CPU fan/water cooling pump header
   4 x system fan headers
   4 x system fan/water cooling pump headers
   3 x addressable RGB Gen2 LED strip headers
   1 x RGB LED strip header
   5 x M.2 Socket 3 connectors
   4 x SATA 6Gb/s connectors
   1 x front panel header
   1 x front panel audio header
   1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
   2 x USB 3.2 Gen 1 headers
   2 x USB 2.0/1.1 headers
   1 x noise detection header
   2 x Thunderbolt add-in card connectors
   1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
   1 x power button
   1 x reset button
   1 x reset jumper
   1 x Clear CMOS jumper
   2 x temperature sensor headers

   Back Panel Connectors
   1 x Q-Flash Plus button
   1 x Clear CMOS button
   2 x SMA antenna connectors (2T2R)
   1 x DisplayPort
   1 x USB Type-C port, with USB 3.2 Gen 1 support
   2 x USB Type-C ports, with USB 3.2 Gen 2x2 support
   7 x USB 3.2 Gen 2 Type-A ports (red)
   4 x USB 3.2 Gen 1 ports
   1 x RJ-45 port
   1 x optical S/PDIF Out connector
   2 x audio jacks

   I/O Controller
   iTE I/O Controller Chip

   BIOS
   1 x 256 Mbit flash
   Use of licensed AMI UEFI BIOS
   PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

   Operating System
   Support for Windows 11 64-bit

   Form Factor
   E-ATX Form Factor; 30.5cm x 26.0cm
