Дънна платка ASRock B760M-HDV/M.2, B760, LGA1700, DDR5, PCI-E 4.0 (HDMI&DP&VGA), 2x M.2, 4x SATA 6Gb/s, 1x USB 3.2 Gen 1 Type-C, 3x USB 3.2 Gen 1 Type-A, Micro ATX

ASRock B760M-HDV/M.2

• Supports 14th, 13th & 12th Gen Intel Core Processors (LGA1700)
• 7+1+1 Power Phase
• Supports DDR5 7200MHz (OC)
• 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key E for WiFi
• Graphics Output Options: HDMI, DisplayPort, D-Sub
• Realtek ALC897 7.1 CH HD Audio Codec
• 4 SATA3, 1 Hyper M.2 (PCIe Gen4 x4),
  1 Ultra M.2 (PCIe Gen3 x4)
• 1 USB 3.2 Gen1 Type-C (Rear),
  5 USB 3.2 Gen1 Type-A (3 Rear, 2 Front),
  6 USB 2.0 (2 Rear, 4 Front)
• Dragon 2.5G LAN

• Supports ASRock Auto Driver Installer



Tech specs:

• CPU

  - Supports 14th, 13th & 12th Gen Intel Core Processors (LGA1700)
  - Supports Intel Hybrid Technology
  - Supports Intel Turbo Boost Max 3.0 Technology
  - Supports Intel Thermal Velocity Boost (TVB)
  - Supports Intel Adaptive Boost Technology (ABT)

• Chipset

  - Intel B760

• Memory

  - Dual Channel DDR5 Memory Technology
  - 2 x DDR5 DIMM Slots
  - Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)*
  - Max. capacity of system memory: 96GB
  - Supports Intel® Extreme Memory Profile (XMP) 3.0

  * 1DPC 1R Up to 7200+ MHz (OC), 5600 MHz Natively.
  1DPC 2R Up to 6800+ MHz (OC), 5200 MHz Natively.



• BIOS

  - 128Mb AMI UEFI Legal BIOS with GUI support



• Graphics

  - Intel Xe Graphics Architecture (Gen 12)
  - 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz
  - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
  - 1 x D-Sub, supports max. resolution up to Full HD (1920x1080) 60Hz

  * Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.



• Audio

  - 7.1 CH HD Audio (Realtek ALC897 Audio Codec)



• LAN

  - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
  - Dragon RTL8125BG
  - Supports Dragon 2.5G LAN Software
  - Smart Auto Adjust Bandwidth Control
  - Visual User Friendly UI
  - Visual Network Usage Statistics
  - Optimized Default Setting for Game, Browser, and Streaming Modes
  - User Customized Priority Control



• Slots

  CPU:
  - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
  - 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)*
  - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

  * Supports NVMe SSD as boot disks



• Storage

  Chipset:
  - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen3x4 (32 Gb/s) modes**
  - 4 x SATA3 6.0 Gb/s Connectors

  * Supports Intel® Volume Management Device (VMD)
  ** Supports NVMe SSD as boot disks



• RAID

  - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices



• USB

  - 1 x USB 3.2 Gen1 Type-C (Rear)
  - 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front)
  - 6 x USB 2.0 (2 Rear, 4 Front)

  * All USB ports support ESD Protection



• Connector

  - 1 x SPI TPM Header
  - 1 x Chassis Intrusion and Speaker Header
  - 1 x RGB LED Header*
  - 3 x Addressable LED Headers**
  - 1 x CPU Fan Connector (4-pin)***
  - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
  - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector
  - 1 x Front Panel Audio Connector
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
  - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

  *Supports in total up to 12V/3A, 36W LED Strip
  ** Support in total up to 5V/3A, 15W LED Strip
  *** CPU_FAN1 supports the fan power up to 1A (12W).
  **** CPU_FAN2/WP supports the fan power up to 2A (24W).
  ***** CHA_FAN1~2/WP support the fan power up to 2A (24W).
  CPU_FAN2/WP and CHA_FAN1~2/WP can auto detect if 3-pin or 4-pin fan is in use.



• Rear Panel I/O

  - 2 x Antenna Mounting Points
  - 1 x D-Sub Port
  - 1 x HDMI Port
  - 1 x DisplayPort 1.4
  - 1 x USB 3.2 Gen1 Type-C Port
  - 3 x USB 3.2 Gen1 Type-A Ports
  - 2 x USB 2.0 Ports
  - 1 x RJ-45 LAN Port
  - HD Audio Jacks: Line in / Front Speaker / Microphone



• Form Factor

  - Micro ATX Form Factor: 9.6-in x 7.9-in, 24.4 cm x 20.1 cm



• OS

  - Microsoft Windows® 10 64-bit / 11 64-bit
