| Общи Характеристики | ||
|---|---|---|
| Packaged Quantity | 1 | |
| Система | ||
| Type | Server | |
| шаси | ||
| Form Factor | Rack-mountable | |
| Front Accessible Bays Qty | 1 | |
| Hot-Swap Bays Qty | 4 | |
| Server Storage Bays | Hot-swap | |
| Server Swappable Drive Interface | SATA | |
| Server Swappable Drive Form Factor | 3.5 | |
| Процесор | ||
| Type | Xeon Silver | |
| Installed Qty | 1 | |
| Max Supported Qty | 2 | |
| Manufacturer | Intel | |
| Clock Speed | 2,8 GHz | |
| Processor Number | 4309Y | |
| Number of Cores | 8-core | |
| Server Scalability | 2-way | |
| Max Turbo Speed | 3,6 GHz | |
| Дънна платка | ||
| Chipset Type | Intel C621A | |
| RAM | ||
| Technology | DDR4 SDRAM | |
| Data Integrity Check | ECC | |
| Features | Memory scrubbing, Single Device Data Correction (SDDC), Adaptive Double-Device Data Correction (ADDDC), Memory Mirroring, Dual rank, Independent Memory Mode, Slots 17 - 32 are available in two-processor configuration only | |
| Memory Speed | 2667 MHz | |
| Configuration Features | 1 x 16 GB | |
| Empty Slots | 31 | |
| Slots Qty | 32 | |
| Installed Size | 16 GB | |
| Max Supported Size | 10 TB | |
| Контролер за съхранение | ||
| Interface Type | Serial ATA-600 | |
| Харддиск | ||
| Type | No HDD | |
| Втори твърд диск | ||
| Type | None | |
| Трети твърд диск | ||
| Type | None | |
| Четвърти твърд диск | ||
| Type | None | |
| Оптично съхранение | ||
| Drive Type | No optical drive | |
| Второ оптично съхранение | ||
| Type | None | |
| Drive Type | No optical drive | |
| Празен диск | ||
| Type | None | |
| Дисплей | ||
| Type | None. | |
| Видео изход | ||
| Video Interfaces | VGA | |
| Аудио вход | ||
| Type | None | |
| Принтер | ||
| Type | None | |
| Работа в мрежа | ||
| Remote Management Controller | Integrated Remote Management Controller (iRMC S5) | |
| Разширителни гнезда | ||
| Bays | 1 (total) / 1 (free) x external 5.25 (9.5mm height), 4 (total) / 4 (free) x hot-swap 3.5 | |
| Слотове за разширение | ||
| Slots | 2 PCIe 4.0 x16 - low-profile, 1 PCIe 4.0 x8 - low-profile, 1 PCIe 4.0 x16 - low-profile (2 processors must be installed) | |
| Осигурена ОС | ||
| Type | No operating system | |
| Захранващо устройство | ||
| Type | Power supply - hot-plug | |
| Voltage Required | AC 100-240 | |
| Frequency Required | 50/60 | |
| Power Provided | 900 Watt | |
| Installed Qty | 1 | |
| Max Supported Qty | 2 | |
| Nominal Voltage | AC 120/230 V | |
| 80 PLUS Certification | 80 PLUS Platinum | |
| Размери и Тегло | ||
| Width | 48,22 cm | |
| Depth | 80,745 cm | |
| Height | 4,27 cm | |
| Weight | 18,2 kg | |
| Обслужване и поддръжка | ||
| Type | 3-year warranty | |
| On-Site Warranty | On-site | |
| Разни | ||
| Height (Rack Units) | 1 | |
| Color Category | Black | |
