Name: Мрежови диск (NAS) Qnap TVS-h874X-i9-64G, шестядрен Intel Core i9 3.3/4.7 GHz, без твърд диск (16x 3.5-inch SATA 6Gb/s, 3Gb/s), 32GB RAM, 2x 10/100/1000/2500 LAN, 2x 10/100/1000/10000 LAN, 2x USB 3.2 Gen 2
Brand: Qnap
SKU: NASQNAPTVSH874XI964G
Price: 5707.70 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси Документация

TVS-h874

Highly-reliable ZFS-based storage with PCIe Gen 4 expandability for 10/25GbE connectivity, M.2 NVMe SSD caching and multi-threads processors for virtualization applications

With an Intel® Core™ multicore-core Processor to support the ZFS-based QuTS hero operating system, the TVS-h874 SMB NAS ensures data integrity and supports block-level inline data deduplication and compression, near-limitless snapshots, real-time SnapSync, and SSD optimization. Whether for mission-critical file servers, virtualization servers, collaborative video editing, or efficient data backup and recovery applications, the TVS-h874 delivers an ideal NAS solution. The high-performance TVS-h874 provides PCIe Gen 4 (up to twice the transmission speed of Gen 3) expandability, M.2 NVMe SSD caching, and 2.5GbE/10GbE connectivity for high-speed virtualization network environments.

Category	Specification
CPU	Intel® Core™ i9 16-core (8P+8E) / 24-thread Processor
CPU Architecture	64-bit x86
Graphic Processor	Intel® UHD Graphics 770
Floating Point Unit	Supported
Encryption Engine	AES-NI
Hardware-accelerated Transcoding	Supported
System Memory	64 GB SODIMM DDR4
Maximum Memory	64 GB (2 × 32 GB)
Memory Slot	2 × SODIMM DDR4
Flash Memory	5 GB (Dual boot OS protection)
Drive Bay	8 × 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility	3.5" SATA HDD, 2.5" SATA SSD
Hot-swappable	Not supported for M.2 SSD
M.2 Slot	2 × M.2 2280 PCIe Gen 4 ×4 (NVMe Gen 3 and above)
SSD Cache Acceleration	Supported
GPU Pass-through	Supported
2.5GbE Ethernet Port	2 × 2.5G/1G/100M/10M
10GbE Ethernet Port	2 × 10GBASE-T (10G/5G/2.5G/1G/100M)
Wake on LAN (WOL)	Supported
Jumbo Frame	Supported
PCIe Slot	Slot 1: PCIe Gen 4 ×16 (preinstalled 10GbE adapter) Slot 2: PCIe Gen 4 ×4
USB 3.2 Gen 2 Ports	1 × Type-C, 2 × Type-A (10 Gbps)
HDMI Output	1 × HDMI 1.4b (4096 × 2160 @ 30Hz)
Form Factor	Tower
LED Indicators	HDD 1–8, Status, LAN, USB, M.2
LCD Display / Button	Supported
Buttons	Power, Reset, USB Copy
Dimensions (H × W × D)	180.2 × 329.3 × 279.6 mm (excluding foot pad)
Weight (Net)	7.34 kg
Weight (Gross)	8.99 kg
Operating Temperature	0–40°C (32–104°F)
Storage Temperature	-20–70°C (-4–158°F)
Relative Humidity	5–95% RH (non-condensing), wet bulb 27°C
Power Supply Unit	350W (PWR-PSU-350W-DT01), 100–240V
Power Consumption (Disk Standby)	72.331 W
Power Consumption (Typical Operating)	96.247 W (fully populated with WD10EFRX drives)
Fan	System: 2 × 120mm (12VDC), CPU: 1 × 60mm (12VDC)
System Warning	Buzzer
