Name: Мрежови диск (NAS) Qnap ES1686dc-R2-2142IT-128G, осемядрен Intel Xeon D-2142IT 1.9GHz, без твърд диск (16 x 3.5-inch SAS 12Gb/s, 6Gb/s), 64GB RAM, 2x 10/100/1000 LAN, 2x USB 3.2 Gen 1
Brand: Qnap
SKU: NASQNAPES1686DCR22142IT128G
Price: 26736.36 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси

ES1686dc R2

High Availability Enterprise NAS with Dual Active Controllers

Ensure uninterrupted mission-critical business operations with the high-availability ES1686dc R2 NAS. With redundant controllers and power supplies, it minimizes downtime, allowing seamless component replacement without disruption, ensuring reliability and continuity for enterprises.

Dual active-active controllers
Dual active-active controllers provide supreme uptime and redundancy to ensure high availability.
NVRAM module
NVRAM reduces the risk of losing write cache data if unexpected power failure occurs.
QES operating system
Supports ZFS near-limitless snapshots, SnapSync, block-level data deduplication, and inline data compression.
Storage for virtualization
Supports VMware® vSphere®, Windows Server® and Citrix® XenServer® for storage virtualization.
10GbE SFP+ ports
Four 10GbE SFP+ ports (per controller) accelerate virtualization, large file sharing, and intensive data transfer.
PCIe Gen 3 slots
Two PCIe slots (per controller) allow for adding 10GbE/25GbE networking cards to increase application performance.

Category	Specification
Number of Controller Modules	2
CPU	Intel® Xeon® D-2142IT 8-core 1.90 GHz processor (burst up to 3.0 GHz) per controller
CPU Architecture	64-bit x86
Floating Point Unit	Supported
Encryption Engine	AES-NI
System Memory	64 GB RDIMM DDR4 ECC per controller
Maximum Memory	1024 GB (16 × 64GB) or 512 GB (8 × 64GB) per controller
Memory Slots	16 × R-DIMM/LR-DIMM DDR4 or 8 × R-DIMM/LR-DIMM DDR4 per controller
Memory Type Restriction	Only one DIMM type allowed at a time (RDIMM or LRDIMM, not mixed)
Flash Memory	4 GB (Dual boot OS protection)
Drive Bays	16 × 3.5-inch bays, SAS 12Gb/s (backward-compatible to SAS 6Gb/s)
Drive Compatibility	3.5" SAS HDD, 2.5" SAS HDD, 2.5" SAS SSD
Hot-Swappable Drives	Yes
SSD Cache Acceleration Support	L1 ARC Read Cache (RAM), L2 ARC Read Cache (SSD), ZIL Write Cache (NVRAM C2F)
Cache for Copy To Flash (C2F)	1 per controller (64GB M.2 SSD)
Gigabit Ethernet Ports (RJ45)	3 per controller (1 for remote management)
10 Gigabit Ethernet Ports	4 × 10GbE SFP+ per controller
Wake on LAN (WOL)	Supported
Jumbo Frame	Supported
PCIe Slots	2 per controller (PCIe Gen 3 x8, CPU-connected)
PCIe Card Dimensions	215 × 68.9 × 18.76 mm (8.46 × 2.71 × 0.74 inches)
USB Ports	2 × USB 3.2 Gen 1 per controller (engineering use only)
Form Factor	3U Rackmount
LED Indicators	Power, system status, RAID state, memory/fan/PSU failure, temperature, storage threshold, takeover status, PSU unplugged, JBOD status LCD
Buttons	Power, Reset
Dimensions (H × W × D)	132 × 446.2 × 587.75 mm
Weight (Net)	30.22 kg
Weight (Gross)	34.92 kg
Operating Temperature	0–40 °C (32–104 °F)
Storage Temperature	-20–70 °C (-4–158 °F)
Relative Humidity	5–95% RH non-condensing (wet bulb: 27°C / 80.6°F)
Power Supply Unit	Redundant hot-swap PSU, 90–264 VAC, 700W
Power Consumption (Typical)	500.87 W (fully populated drives)
Fans	Hot-swappable fan module (60×60×38 mm, 16000 RPM, 12V/2.8A × 3)
System Warning	Buzzer
