Дънна платка MSI MEG Z690I UNIFY, Z690, LGA1700, DDR5, PCI-E 5.0 (DP&HDMI), 3x M.2, 4x SATA 6Gb/s, 2x USB Type-C, mITX

MSI MEG Z690I UNIFY

The World Record Breaker – MEG Motherboard

With years of experience, MSI is no stranger to building high-performance motherboards. Our R&D and engineering teams have reviewed countless designs, evaluated a wide selection of high quality components, and developed products for reliability even under extreme conditions.

Enhanced Performance

High performance MSI motherboards are loaded with advanced features and the latest technology to overwhelm any challenge at hand no matter whether you’re a gamer, prosumer, or PC enthusiast.

Specifications:

• Socket: 1700
• Chipset: Intel® Z690 Chipset
• DDR5 Memory: 6800+(OC) , 6666(OC) , 6600(OC) , 6400(OC) , 6200(OC) , 6000(OC) , 5800(OC) , 5600(JEDEC) , 5400(JEDEC) , 5200(JEDEC) , 5000(JEDEC) , 4800(JEDEC) MHz
• Memory Channel: Dual
• DIMM Slots: 2
• Max Memory (GB): 96
• PCI-E x16: 1
• SATAIII: 4
• M.2 Slot: 3
• RAID: 0/1/5/10
• WiFi & Bluetooth: Intel® Wi-Fi 6E module
• Thunderbolt 4: 2x USB Type-C up to 40G, Charging support up to 5V/3A, 15W, 2x Mini DisplayPort input ports
• USB 3.2 ports (Front): 1(Gen2x2, Type C), 2(Gen1, Type A)
• USB 3.2 ports (Rear): 2(Gen2, Type A), 4(Gen1, Type A)
• USB 2.0 ports (Front): 2
• Audio ports (Rear): 7.1-Channel High Definition Audio (Realtek® ALC4080 Codec)
• DisplayPort: 1
• HDMI: 1
• DirectX: 12
• Operating System: Support for Windows® 11 64-bit, Windows® 10 64-bit
• Form Factor: Mini-ITX
• Dimension: 6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
